VARO Shelving and Stocking System, Workshop Lorries, Assortments, Vehicle Modules

Modular package D:

Installation Driver’s side: Installation Passenger’s side:

Module 44 – 60 Module 44 – 60
Width: 1.004 mm

Height:
1.046 mm

(PT = partial thread) Depth370 mm
(PT = partial thread)

Basis block Weight Basis block Weight
Basic module: Art. No. 9009 44 60 1 approx 21 kg Basic module: Art. No. 9009 44 60 1 approx 21 kg
Premium module: Art. No. 9009 44 60 3 approx 28 kg Premium module: Art. No. 9009 44 60 3 approx 28 kg
(PT = partial thread)
Select your individual modular equipment:
Basic module or premium module (incl. drawer and shelf flap)
You can add further drawers and shelf flaps in different heights, as well as more shelfs and shelf tank bottoms to your vehicle equipment
(see accessories from Page 18/890).
Floors and side panels:
For standard vans (without a window, bench, separating grid, etc. in the cargo space)

Model from Model Wheelbase Excess Drive type Height Art. No. of floor Art. No. of side Image No.
length panel
Citroen Jumpy 2007 3.000 mm – Front Normal 9011 331011141 9011 331011223 2, 4, 6
9011 331011225 1, 3, 5
Citroen Jumpy 2016 2.925 mm – Front Normal 9011 1000005157 9011 1000005160 2, 4, 6
9011 1000005159 1, 3, 5
Fiat Scudo 2007 3.000 mm – Front Normal 9011 331011141 9011 331011223 2, 4, 6
9011 331011225 1, 3, 5
NissanNV200 2010 2.725 mm – Front Normal 9011 331017186 9011 1000001830 2, 4, 6
Peugeot Expert 2007 3.000 mm – Front Normal 9011 331011141 9011 331011223 2, 4, 6
9011 331011225 1, 3, 5
Peugeot Expert 2016 2.925 mm – Front Normal 9011 1000005157 9011 1000005160 2, 4, 6
9011 1000005159 1, 3, 5
Toyota Proace – 3.000 mm – Front Normal 9011 331011141 9011 331011223 2, 4, 6
9011 331011225 1, 3, 5
Toyota Proace 2016 2.925 mm – Front Normal 9011 1000005157 9011 1000005160 2, 4, 6
9011 1000005159 1, 3, 5

2 6 10 4

5 9
1 3
