Truckline

Edge Protection Angle

• Ideal belt fixation due to side guidance or slot
• For the protection of the belt strap in case of sharp-edged transport
material
Art. No. 4984 7 80 80 and 4984 7 80 85:
• Suitable for load-securing of paper rolls and barrels
4984 7 25 4984 7 50 4984 7 50 80

4984 7 60 90 4984 7 80 80

4984 7 80 85 4984 7 140 195
Technical Data
Side length Width Slot guidance Guide edge
Article No. Article Description QTY mm mm up to mm up to mm
4984 7 25 EDGE PROTECTION 25MM BLACK z 100 37x37 40 25
4984 7 50 EDGE PROTECTION 50MM BLACK 10 60 x 60 60 - 50
4984 7 50 80 EDGE PROTECTION 50/80MM BLACK 10 90 x 90 105 50 80
4984 7 60 90 EDGE PROTECTION 60/90MM GREY 1 90 x 90 127 60 90
4984 7 80 80 EDGE PROTECTION 80/80MM YELLOW 1 120 x 155 140 80 80
4984 7 80 85 EDGE PROTECTION 80/85MM RED 1 140 x 185 145 80 85
4984 7 140 195 EDGE PROTECTION 130/170MM BL. 1 130 x 170 145 - 60

Edge Protection

• Protects belt webbing of sharp-edged goods to be transported
Art. No. 4984 50 1
• Made of polyurethane (PU), flexible
Art.-No. 4984 50 2
• made of polyurethane (PU), flexible, with slit for a better insertion of
the belt 4984 50 2
4984 50 1
Art. No. 4984 7 190 190
• Made of polyethylene (PE)

Article No. Article Description QTY
4984 50 1 EDGE PROTECTION WHITE 320X95MM 1
4984 50 2 PK(5)EDGE PROT.TRANS.300X100MM 1
4984 7 190 190 EDGE PROTECT.ANGLE 1000X190MM 1 4984 7 190 190
4984 7 190 EDGE PROTECTION 750/190MM 1 4984 7 190
