Truckline

End fitting for airline tracks

Technical Data
art. no. strip breadth breaking strain FB
4984 900 25 mm 1000 daN
4984 901 25 mm 1000 daN

Article No. Article Description QTY
4984 900 END FIT. F.AIRL.TRACK W.EYELET 5
4984 901 END FIT. F.AIRL.TRACK W.RING 5

Double end fitting for airline tracks

Technical Data
art. no. strip breadth breaking strain FB
4984 902 25 mm 2000 daN
4984 903 50 mm 800 daN
4984 903
Article No. Article Description QTY
4984 902 2-END FIT. F.AIRL.TRACK W.EYEL 5
4984 903 2-END FIT. F.AIRL.TRACK W.RING 5

4984 902

Screw fitting for airline tracks
• M8 screw fitting consisting of:
- plate connector, screw and nut

Article No. Article Description QTY
4984 904 25 SCREW FITTING F.AIRLS. M8X25 10
4984 904 SCR.FIT. F. AIRL. TRACKS 10
4984 904 40 SCREW FITTING F.AIRLS. M8X40 10
4984 904 60 SCREW FITTING F.AIRLS. M8X60 10
Contents each Screw fitting:
• plate connector
• screw and nut M8

Slot nut for airline rail

• Slot nut with M6 thread

Article No. Article Description QTY
4984 911 2 6 SLOT NUT 2XM6 GV 10
4984 911 3 6 SLOT NUT 3XM6 GV 10 4984 911 2 6

4984 911 3 6
