Truckline

Slinging chains with shortening hooks, 4 leg

• With shortening hooks
• Load carrying capacity: 0° – 45° = 4,250 kg, 46° – 60° = 3,000 kg
Chain link thickness: 8 mm
• Load carrying capacity: 0° – 45° = 6,700 kg, 46° – 60° = 4,750 kg
Chain link thickness: 10 mm
• Load carrying capacity: 0° – 45° = 11,200 kg, 46° – 60° = 8,000 kg
Chain link thickness: 13 mm
• Quality class 8
• EN 818 - 4 + A1

Article No. Article Description QTY
4983 9 4 2 8 4-LEG-SLING.CHAIN VKH 2M/8MM 1
4983 9 4 2 10 4-LEG-SLING.CHAIN VKH 2M/10MM 1
4983 9 4 2 13 4-LEG-SLING.CHAIN VKH 2M/13MM 1
4983 9 4 4 8 4-LEG-SLING.CHAIN VKH 4M/8MM 1
4983 9 4 4 10 4-LEG-SLING.CHAIN VKH 4M/10MM 1
4983 9 4 4 13 4-LEG-SLING.CHAIN VKH 4M/13MM 1

Technical data subject to change.
Availability subject to country specific rules and regulations. www.iconridge.com Source: Theo Förch GmbH & Co. KG 878
