PA Spiral Hose

• With kink protection spring
• Caution: PA spiral hoses are equipped with M16x 1.5 adapters
(2x). Other adapters are available separately.

Technical Data
Article No. Article Description QTY Art. No. Thread Coils Effective length Total length
3420 10 SPI.HOSEYELL.PAM16X1.519WIN 1 3420 10 M 16 x 1.5 19 3.66 m 4.20 m
3420 20 SPI R. HOSE RED PA M16X1.5 19W 1 3420 20 M 16 x 1.5 19 3.66 m 4.20 m
3420 30 SP.HOSE BLACK PA M16X1.5 19WIN 1 3420 30 M 16 x 1.5 19 3.66 m 4.20 m
Spiral cables PUR

• ester-polyurethane and ether-polyurethane coil provide high mecha-
nical stability and flexibility
• high elasticity, good abrasion and break resistance, even at low tem-
peratures (-40°C)
• resistant to UV rays and aggressive materials such as oil, fuel, acids,
alkali and ozone
• polyamide and strain relief spring on each side prevents fractures at
the joints
• fulfils all relevant requirements according to DIN 74323 and DIN
74324
• warning: PUR spiral cables are equipped with M16 x 1.5 adapter
(2x). If using other adapters, these must be ordered separately.

Technical Data
Article No. Article Description QTY thread coils working length
3420 65 SPIRAL CABL. BLACK PUR M16X1.5 1 M16 x 1.5 23 4.00 m
4.00 m
23
M16 x 1.5
3420 66 SPIRAL CABL. YEL. PUR M16X1.5 1
3420 67 SPIRAL CABL. RED. PUR M16X1.5 1 M16 x 1.5 23 4.00 m
4.00 m
23
M16 x 1.5
3420 68 DUO.SP.CA.PUR YEL/RED M16X1.5K 1
3420 69 DUO.SP.CA.PUR YEL/RED M16X1.5L 1 M16 x 1.5 26 4.50 m
Extension Sleeves
• For air coils and coupling head with thread M 16 x 1.5
• Safe use due to ergonomic formed handle
• Suitable for air coils with steel or plastic bend protection

Article No. Article Description QTY
3420 75 EXTENSION SLEEVES SET 1
Included in delivery:1x red, 1x yellow

Technical data subject to change.
