HINGES
HINGES
Gas Struts
Adjustable Force Gas Struts A B D ELECTRICAL
B
D A D D
C C
Gas Struts are available from stock in various diameters in the Stroke
adjustable form. They are pressurised to the maximum force for Stroke Extended length (stud xing)
that Strut size. Gas can be released via a bleed valve, accessible Extended length (stud xing)
from the side, which allows gas to be vented, hence reducing the
force. Ball Joint (B) Eye (E) Ball Joint (B) Eye (E) Clevis fork (C) EMERGENCY
Clevis fork (C)
They are ideal for applications where the exact weights are E L E N L P N P
unknown, thus making force calculations difficult. K
F F K J M
G J G H M
H
Stock sizes of Gas Struts H H
Strut Size Stroke Extended length Force INSTRUCTIONS FOR VALVE ADJUSTMENT GENERAL
6-15 60 160 Adjustable 1. Mount gas strut on the application with the rod pointing
6-15 100 240 Adjustable downwards and the valve at the top.
6-15 150 340 Adjustable 2. The gas strut will probably have more force than required so
8-18 100 250 Adjustable do not attempt to force the door or lid shut.
8-18 150 350 Adjustable 3. Insert an allen key into the grub screw on the valve. Undo
8-18 200 450 Adjustable slightly until the sound of gas escaping is heard. Quickly HANDLES
8-18 250 550 Adjustable re-seal the valve by tightening the grub screw.
DO NOT OVER-TIGHTEN.
10-23 200 450 Adjustable 4. If using two gas struts per application, adjust each one in
10-23 250 550 Adjustable turn until the correct force is achieved. It is important not to
10-23 300 650 Adjustable release too much gas in one go.
10-23 350 750 Adjustable 5. Warning do not remove grub screw
HINGES
Gas Strut Brackets — Heavy Duty Gas Strut Brackets
Anodised aluminium
Part No. 0825 14962 is only suitable for 8-18 gas strut eyes
Part No.17193 is suitable for both 8-18 and 10-23 gas strut IRONWORK
eyes. Supplied as a male & female set
Part No. 0825 20127 is suitable for 8-18 and 10-23 gas strut
eyes Supplied as a female bracket only GSBE1
GSBB1
LIGHTING
GSBB2
0825 14962
LOCKS
17193
GSBE2
STEPS
Part No. A B C D E F Description Kg Finish
0825 20127
GSBB1 69 30 23 55 18 6-15 Ball Bracket 0.055 ZPS
Part No. A B C D E F G H Kg Finish GSBB2 69 39 24 55 28 8-18 Ball Bracket 0.055 ZPS
0825 14962 60 28 8 6 40 22 29 46 0.5 BAA GSBB3 69 30 24 55 18 10-23 Ball Bracket 0.06 ZPS
17193 80 35 8 19 46 33 32 60 0.21 BAA GSBE1 95 26 18 76 19 32 6-15 Eye Bracket 0.03 ZPS VENTILATION
0825 20127 80 33 32 60 18 0.1 BAA GSBE2 95 28 18 76 20 30 8-18 Eye Bracket 0.075 ZPS
