the network are IDS (intrusion detection systems) and IPS
(intrusion prevention systems) that monitor record and may
block suspicious activity. The application firewall in the DMZ is
behind a packet-filtering router to clear out most of the bad
traffic before it gets to the application firewall.
Inside on the network is more segmentation between various
departments and systems to restrict traffic from areas it does not
need to access.

Each device connected to the network is also secured with
antivirus, a firewall, and Host-based IPS.
The above is an example of a layered network defense.

Encryption of Network Traffic
There are several ways to encrypt network traffic depending on
the layer in the OSI stack, where the encryption is to be done. In
many cases, data may be encrypted more than once. For
example, an encrypted email sent over a wireless connection
will be encrypted at the application layer (email) and again at
the data link layer (WPA2).

Datalink layer encryption
The lowest level of encryption is at the data link layer. This
encrypts the data between two adjacent devices. An example of
this is to use WPA2 to encrypt data between a laptop and the
wireless access point- a link-layer encryption. The problem with
link-layer encryption is that the data must be decrypted at each
end of the link, and if the data is going to transmit across
another link, then the data must be re-encrypted. An example of
this problem is when an organization is using handheld wireless
