Lightning Service
™
Specials from Blanks • General Applications • HSS

(continued)
Specials from Blanks • General Applications • HSS

Spiral Point Hand

Spiral Flute

uncoated uncoated uncoated uncoated max D pitch
style 2-fl ute 3-fl ute 4-fl ute 6-fl ute L L3 L2 D limit min
M2.5
Hand — T, P, B 65291 65302 – – 1.81 0.50 – 0.141 5 0.30
Spiral-Point Gun — P, B 65384 – – – 1.81 0.50 – 0.141 5 0.30
Spiral-Flute 30º — P, B 65498 – – – 1.81 0.50 – 0.141 5 0.30
Spiral-Flute 49º — P, B 65507 – – – 1.81 0.50 – 0.141 5 0.30
M3
Hand — T, P, B 65292 65303 64852 – 1.94 0.63 – 0.141 5 0.30
Spiral-Point Gun — P, B 65385 – – – 1.94 0.63 – 0.141 5 0.30
Spiral-Flute 49º — P, B 65508 – – – 1.94 0.63 – 0.141 5 0.30
M3.5
Hand — T, P, B 65293 65304 65850 – 2.00 0.69 – 0.141 7 0.30
Spiral-Point Gun — P, B 65386 64849 – – 2.00 0.69 – 0.141 7 0.30
Spiral-Flute 30º — P, B – 65515 – – 2.00 0.38 0.69 0.141 7 0.30
Spiral-Flute 49º — P, B – 65526 – – 2.00 0.38 0.69 0.141 7 0.30
Oversized
Hand — T, P, B – 65783 – – 2.00 0.69 – 0.141 13 0.30
Spiral-Point Gun — P, B – 65416 – – 2.00 0.69 – 0.141 13 0.30
M4
–
Hand — T, P, B 65294 65305 65317 – – – 2.13 0.75 0.75 0.168 7 7 7 0.30
–
65393
65387
2.13
–
0.168
0.75
0.30
Lightning Service Spiral-Flute 49º — P, B 65411 65527 65433 – – – 2.13 0.38 0.75 0.168 13 0.30
Spiral-Point Gun — P, B
65516
–
–
0.168
0.38
2.13
0.30
Spiral-Flute 30º — P, B
–
7
–
Oversized
2.13
0.75
0.30
65784
–
0.168
–
Hand — T, P, B
2.13
0.168
0.75
–
0.30
–
–
13
Spiral-Point Gun — P, B
M4.5
Hand — T, P, B – 65306 65318 – 2.38 0.88 – 0.194 7 0.30
Spiral-Point Gun — P, B 65388 65394 – – 2.38 0.88 – 0.194 7 0.30
Spiral-Flute 30º — P, B – 65517 – – 2.38 0.50 0.88 0.194 7 0.30
Spiral-Flute 49º — P, B – 65528 – – 2.38 0.50 0.88 0.194 7 0.30
Oversized
Hand — T, P, B – – 65434 – 2.38 0.88 – 0.194 13 0.30
