HAND TOOLS

Industrial Safety Welding Oilfield Construction

Punch & Chisel Sets Drift Punches

F•ea2t0u%relsa:rger striking surface than F•eaAtluigrness:holes in 2 or more

standard chisels allows the safe pieces of metal through which a bolt or screw is to be inserted.
use of a larger striking tool and directs more power to the cutting edge.
• Modified parabolic striking end for greater
• Cutting edge is ground to exact angle for easy cutting.
• Two piece design allows the tip to have a separate hardness to prevent resistance to mushrooming and chipping.

peening and allows the tip to be produced straighter to eliminate binding. • For installing pins and rivets and for starting their removal.

• Hardened, quenched, and tempered to precise specifications. Test & Approvals: Federal Spec. GGG-P-831e; ANSI Spec. B209.2
Tip Type: Round
Material: Alloy Steel Material: Tool Steel
Finish: Black Oxide
SKU Overall Length Stock Shape
577-963/8 10 1/8 in Hex

SKU Includes Quantity
(2) Center Punches; (1) Prick Punch; (6) Drive Pin Punches 5/64, 26 per
7/64, 5/32, 11/64, 13/64, 15/64 in; (5) Starting Punches 3/32, 1/8, pouch HAND TOOLS
577-46 3/16, 7/32, 1/4 in; (9) Cold Chisels 1/4 - 13/16 in; (3) Drift Punches 12 per
pouch
1/8, 3/16, 1/4 in
(1) Center Punch; (3) Drive Pin Punches 5/64, 7/64, 11/64 in; (3)
577-2 Starting Punches 1/16, 1/8, 3/16 in; (1) Diamond Point 3/16 in.; (3)
Cold Chisels 5/16, 7/16, 1/2 in Long Aligning Punches

Punches F•eaMtuordeifsie: d parabolic striking end for greater

resistance to mushrooming and chipping.

• For lining up holes in flanges, assemblies,

and for other mating parts and for
removing long pins and shafts.
Test & Approvals: ANSI Spec. B209.2
Tip Type: Round
Material: Tool Steel

SKU Overall Length Stock Shape
577-155/8 16 in Hex

Steel Automatic Center Punches CLAMPS & VISES
Clamps & Spreaders
Features:

• Adjustable for light or heavy markings.
• Threaded replaceable hardened steel point and shaft.

Tip Type: Pointed

SKU Overall Length Stock Shape
318-79 5 in Straight

Line-Up Punches - Full Finish SL300 One Handed

F•eaUtsuerdesto: align holes through which rivets, pins, or bolts will be inserted. Bar Clamps / Spreaders
• Not for use when driving pins, rivets, or bolts.
• Variable point size, shank size, and taper length for the perfect alignment. •FeaQtuuirceks-:Change jaw quickly converts from clamp
• Black oxide finish for additional rust protection.
to spreader and requires no tools.
Tip Type: Round
Material: Alloy Steel • Constructed of high-tech reinforced resin for strength and durability.
• Patented pistol grip design enhances comfort and ease of use.
• Non-marring pads grip firmly and protect work.
• Ideal for clamping/gluing, holding work for sawing/

drilling, and positioning work for fastening.

• I-beam bar reduces flexing and bowing.

Load Cap.: 300 lb

SKU Overall Length Stock Shape SKU Opening Size Throat Depth
479-22005 15 in Hex 586-512QCN 12 in 3 3/16 in
