HAND TOOLS

Industrial Safety Welding Oilfield Construction

SQ Series

Bar Clamps

F•eaRteugruelsa:r-duty all-steel bar clamp.
• Comes with standard rail profile and standard pad.

Body Finish: Satin
Handle Type: Sliding Pin T-Handle

SKU Opening Throat Load Cap. Style Spindle Magnetic Square 90/45 Degree HAND TOOLS
Size Depth Diam
013-SQ-4 6 in 4 3/4 in 1330 lb Standard Pad 5/8 in •FeaMtuurlteipsu: rpose magnetic square gives you extra help on the job.
013-SQ-8 8 in 5 1/2 in 2,660 lb Heavy-Duty Pad 0.78 in • Quality ferrite magnets for fast and easy set-up.
013-SQ-12 12 in 5 1/2 in 2,660 lb Heavy-Duty Pad 0.78 in • Easily holds 90- and 45-degree angles for welding.

Height: 4 3/8 in
Length: 3 3/4 in

Heavy Duty SKU Load Cap.
013-WMS-1 66 lb
Copper F-Clamps
Heavy Lifting Magnet
F•eaStpuarreks-:Duty copper-plated spindle extends the life of the clamp by
F•eaEtausrieesr :to turn on than standard magnetic lifters.
protecting the spindle and pad from harmful welding spatter. • Provides more concentrated flux, resulting

• Quick-Twist Pads are simple and fast to replace with a V-Groove in a safer hold on uneven, dirty or round-
shaped steel.
pad included in every box, or optional serrated pad.
• Effectively exerts full hold force on thinner steel.
• Ergonomic Wilton-Grip® has anti-fatigue properties and
Height: 12 2/3”
provides comfort during repetitive clamping. Length: 6 3/4”
Width: 2 4/5”
• Drop forged arm provides minimal flex under heavy work loads.

Load Cap.: 4,880 lb
Bar Width: 1 9/16 in
Bar Thickness: 25/32 in
Spindle Diam: 7/8 in
Body Material: Extruded Steel

SKU Opening Size Throat Depth
825-86500 12 in 7 in
825-86520 24 in 7 in

SKU Load Cap.
474-8100387 Full Saturation Breakaway: 1800 lbs

Regular Duty F-Clamps Magnetic Ground Clamps

Features: F•eaOtnu/rOefsf:magnetic clamp enables

• Black oxide spindle resists wear and tear while impeding rust. welder to quickly set up, weld and move on to the next job.
• Drop forged arm provides minimal flex under heavy work loads.
• Swivel pad centers on work piece for a sturdy hold. • Instant ground on flat or pipe.
• Sturdy tommy bar is engineered for durability and comfort. • Provides strong grip on flat or round surfaces.

Load Cap.: 1,800 lb
Bar Width: 1 in
Bar Thickness: 15/32 in

SKU Opening Throat Spindle Handle Type SKU Load Cap. Height Length Width
Size Depth Diam 474-8100746 90 lb 2 3/10 in 2 9/10 in 1 9/10 in
825-86230 24 in 4 3/4 in 5/8 in Tommy Bar 474-8100747 200 lb 2 3/5 in 2 7/10 in
825-86220 18 in 4 3/4 in 3/4 in Sliding Pin; Tommy Bar 4 in
825-86200 8 in 4 3/4 in 3/4 in Sliding Pin; Tommy Bar
825-86210 12 in 5 1/2 in 3/4 in Sliding Pin; Tommy Bar 229
