HAND TOOLS

Industrial Safety Welding Oilfield Construction

Automatic Locking C Clamps 400 Series C-Clamps

Features: Features:

• Automatically locks on without adjusting. • Drop forged steel frame, regular duty with extra deep-throat.
• Ergonomically shaped handle. • Black oxide spindles and perma-pad® resist corrosion and are replaceable.
• Set & Forget™ Set desired clamp pressure, from slight to extreme and • Innovative frame geometry for maximum strength.

jaws automatically adjust to any size with equal grip pressure. Body Material: Forged Steel
Body Material: Chrome Molybdenum Steel Handle Type: Sliding Pin
Handle Material: Steel

SKU Opening Throat Depth Length Handle Material SKU Opening Size Throat Depth Pressure Spindle Dia HAND TOOLS
Size 825-14242 4 1/4 in 3 1/4 in 6,200 lb 3/4 in
337-10201 3 1/2 in 11 3/4 in Nickel Plated Steel 825-14256 6 1/16 in 4 1/8 in 6,600 lb 3/4 in
337-10200 3 1/2 in 3 3/4 in 11 1/2 in Steel 825-14270 8 1/4 in 5 in 6,900 lb 3/4 in
3 in 825-14284 10 1/8 in 6 in 8,000 lb 3/4 in
825-14298 12 1/4 in 6 5/16 in 9,600 lb 7/8 in

Locking C-Clamps with Regular Tips 400-P Series C-Clamps

Features: Features:

• Wide-opening jaws provide greater versatility • Serrated Perma-Pad® and grooved anvil.
• Copper plated spindles and Perma-Pads® for
in clamping a variety of shapes.
resistance to welding spatter and corrosion.
• Turn screw to adjust pressure and fit. Spindle Dia: 3/4 in
• Constructed of high-grade heat-treated alloy steel. Body Material: Forged Steel
• Guarded release trigger quickly unlocks and protects from accidental release. Handle Type: Sliding Pin
Handle Material: Steel
Pressure: Adjustable
Body Material: Alloy Steel SKU Opening Size Throat Depth Pressure
Handle Type: Vise Grip 825-14257 0 - 6 1/16 in 4 1/8 in 6,600 lb
825-14271 5 in 6,900 lb
SKU Opening Size Throat Depth 8 1/4 in
586-6R 2 1/8 in 1 1/2 in
586-11R 4 in 2 5/8 in
586-18R 8 in 9 1/2 in
586-24R 10 in 15 1/2 in

Ultra Qwik Clamp 540 Series

•FeaPtuusrhe-sb:utton design allows for rapid action Carriage C-Clamps

setting and fine tune thread adjustment. F•eaFtruarmeess: made from high strength ductile iron castings.
• Sliding pin (vise type) handle, single acme thread rolled
• Lightweight: suitable for overhead work.
• Smooth roller clamping action for positive gripping. spindle and oscillating ball and socket tip.
Pressure: 2,450 lb
Body Material: Steel Spindle Dia: 5/8 in
Handle Type: T-Handle Body Material: Cast Iron
Handle Material: Steel Handle Type: Sliding Pin
Handle Material: Steel
SKU
432-781530 SKU Opening Size Throat Depth
825-22005 0 - 6 in 2 3/4 in
© 2016
1.800.678.6577 227
