Page 13 - Avtron Encoders Catalog

Solid Shaft
AV45 (EU-SMART) | XR4F (SMARTSafe )
TM)

MAGNETIC, HEAVY DUTY INCREMENTAL

AV45 Features
• Fits IEC B10 85mm flange
• 8 – 5000 PPR
• -40° to 100°C operation
• Diagnostic LED, remote alarm
• High power outputs with full short
circuit and wiring protection
• Universal TTL & HTL power design
• Direct replacement for Hubner
POG 8, POG 9, other models
• The most rugged B10 flange encoder
ever made! AV45 (XR4F with Level 2 protection) connector option “L”; AV45 with optional over-
speed switch connector option “P”
HAZARDOUS DUTY INCREMENTAL OPTIONS
• Second isolated output
XR4F Features • Overspeed switch (AV45 only)
• Physically identical to AV45 • Foot mounting bracket
• Fits IEC B10 flange • Mating cables
• 8 – 5000 PPR
• -40° to 80°C operation
• Level 1 & Level 2 hazard protection

Output
Model Shaft Size Left PPR Right PPR Line Driver Connector Options Foot Mount Modifications
Channels
AV45 H- 11mm XX- none AV- 900 XX- none AJ- 960 X- none T- M12 Global pinout w/o plug X- none A- A,A–, B,B–, 000- none
N- 10mm AF- 60 AJ- 960 AG- 100 AW- 1000 8- Standard: U- M12 USA pinout w/o plug 1- Toshiba TS2113N Z,Z– 6xx- mechanical
T- 18mm AG- 100 AW- 1000 AH- 120 AY- 1024 5-24V in, 5-15V 2- M23 Leine & Linde pinout 2- Hubner POG/OG overspeed
AH- 120 AY- 1024 AL- 240 AZ- 1200 out hi power w/o plug 3- J. Hubner - FG4 switch
AL- 240 AZ- 1200 AN- 256 A3- 2000 6- Single-Ended: 3- M23 Hubner pinout w/o plug 9xx- Special
AN- 256 A3- 2000 AP- 300 A4- 2048 5-24V in, 5-24V L- Terminal Box (Europe) Foot mount not cable length
AP- 300 A4- 2048 AE- 360 A5- 2500 out H- Terminal Box USA available with dual xx-feet
AE- 360 A5- 2500 AB- 480 AD- 4096 9- Remote TTL: P- Ind. w/ Plug outputs [0.3m] (use
AB- 480 AD- 4096 AQ- 500 A8- 4800 5-24V in, 5V W- 0.45m Cable w/ Connector
AQ- 500 A8- 4800 AR- 512 A9- 5000 fixed out Option “W”)
AR- 512 A9- 5000 AS- 600 A0- Special
AS- 600 A0- Special AV- 900
XR4F as above as above as above X- none Contact Factory as above as above 000- none
H- ATEX Zone 0/20 9xx- Special
12-24V cable length
5- ATEX Zone 1/21 xx-length
12-24V x 0.3m (use
7- ATEX Zone 2/22 w/ Connector
5-24V Option “W”)
F- UL Class I/II, Div 1
12-24V
G- UL Class I/II, Div 2 See manual for all
5-24V options

13
