BIG LIGHT 2017 ∙ OUTDOOR WALL LIGHTS 175

OUT-BEAM OUT-BEAM
Up/down LED
• 690 lumens • 510 lumens
• Uplight is narrow 2° beam, downlight is a 70° • Narrow 2° up and down beam
flood • Excellent for column illumination
• Custom molded lens for superior uplight
performance

Lamp details Lamp details
LED 1x 15W 3000K CRI>80 LED 1x 18W 3000K CRI>80

Product details Product details
120-277V 120-277V
Total consumption: 15W Total consumption: 18W
Material: Aluminum/Glass Material: Aluminum/Glass
W: 5.91 in. H: 5.91 in. D: 6.22 in. W: 5.91 in. H: 5.91 in. D: 6.22 in.

70° 3.35 2° 3.35

25000 25000

5.91” 5.91”

5.91” 5.91”

Variant Item No. Variant Item No.
690lm 510lm
Silver/Gray 229664U Silver/Gray 229694U
Anthracite 229665U Anthracite 229695U
Rust 229667U Rust 229697U
