35 kV: 3M™ Molded Rubber Splice Kits: Single Conductor (1/C)

3M™ Molded Rubber QS CN/JCN Cable Splice Kits 5432 and 5433

3M™ Molded Rubber QS CN/JCN Cable Splice Kits 5432 and 5433 are inline splices designed for use on 35 kV CN or JCN cable. Meets requirements of
IEEE 404.
Important: On all QS kits use the primary insulation O.D. range for final ordering criteria. For copper or aluminum conductor cable, select the correct splice
with connector from the table provided. Jacketing kit is needed for JCN cable.
Each kit makes one splice. Connectors are packed in kits when indicated.
Note: Cable sizes shown below are for standard insulation thickness. Final determining factor is cable insulation O.D. Medium Voltage Splice Kits,

Voltage 35 kV
Number of Conductors Single Conductor
Concentric Neutral (CN), Jacketed
Shielding Type
Concentric Neutral (JCN)
Splice Type Inline
Technology Molded Rubber

Order No. UPC Insulation O.D. Range Conductor Size Connector Included Case Qty. 5 kV–46 kV
5432 054007-02338 1.06”-1.21” (26,9-30,7 mm) 2-1/0 AWG - 1
5432-CI-1A 054007-08357 1.06”-1.21” (26,9-30,7 mm) 1 AWG (Stranded); CI-1A 1
1/0 AWG (Solid)
5432-CI-1/0A 054007-31222 1.06”-1.21” (26,9-30,7 mm) 1/0 AWG (Stranded) CI-1/0A 1
5433 054007-02339 1.12”-1.32” (28,4-33,5 mm) 3/0-4/0 AWG - 1
5433-CI-3/0B 054007-49485 1.12”-1.32” (28,4-33,5 mm) 3/0 AWG CI-3/0B 1
5433-CI-4/0B 054007-49486 1.12”-1.32” (28,4-33,5 mm) 4/0 AWG CI-4/0B 1
