Rotary Switches

• Rotary Canopy Type Switches
• Household Appliances, Fixtures Fig. 1 Fig. 2 Fig. 3 Fig. 4
& Lamps

Cat. Fig. Function Color Poles Terminal No. of Rating Dimensions Bag Master
No. Type Terminals L” x W” x H” Qty Bag Morris Products Line
6 Amps 125VAC
70220 1 On-Off Brass SPST 6" Leads N/A 3 Amps 250VAC 0.97" x 0.8" x 0.37" 1 10 ELECTRICAL
6 Amps 125VAC
70222 2 On-Off Black SPST 6" Leads N/A 3 Amps 250VAC 0.96" x 0.79" x 0.36" 1 10
6 Amps 125VAC
70230 3 Off-On(A)-On(B)-On(A+B) Brass SPST 6" Leads N/A 3 Amps 250VAC 0.86" x 1.03" x 0.34" 1 10
3 Amps 125VAC
70422 4 On-Off Black SPST 6" Leads N/A 1.5 Amps 250VAC 0.60" Dia x 0.73" Ht 1 10
ELECTRICAL
Push ButtonsPush Buttons

• Momentary Contact
• Maintained Contact
• Appliances, Fixtures
• ( ) = Momentary Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 Fig. 7

Cat. Fig. Type Function Color Poles Terminal No. of Rating Dimensions Bag Master
No. Type Terminals L” x W” x H” Qty Bag
Momentary
6 Amps 120VAC
70140 1 Contact Push (On)-Off Black SPST Screw 2 3 Amps 240VAC 0.88" x 0.54" x 0.35" 1 10
Momentary
3 Amps 120VAC
70150 2 Contact Push On-(Off) Red SPST Screw 2 1.5 Amps 240VAC 0.88" x 0.54" x 0.35" 1 10
8 Amps 125VAC
Black
Maintained
70160 3 Contact Push On-Off Plastic SPST 6" Leads N/A 4 Amps 250VAC 0.98" x 0.60" x 1.61" 1 10
1/3HP 125VAC
Maintained
70161 4 Contact Push On-Off Nickel SPST 6" Leads N/A 8Amps 125VAC 0.98" x 0.63" x 0.69" 1 10 Rotary Switches / Pushbutton Switches / Pull Chains
4Amps 250VAC
1/3HP 125VAC
Maintained
6 Amps 125VAC
70200 5 Contact Push On-Off Brass SPST 6" Leads N/A 3 Amps 250VAC 0.97" x 0.80" x 0.36" 1 10
6 Amps 125VAC
Maintained
70210 6 Contact Push On-Off Nickel SPST 6" Leads N/A 3 Amps 250VAC 0.97" x 0.80" x 0.36" 1 10
6 Amps 125VAC
Miniature
70165 7 Push Button On-Off Black SPST 6" Leads N/A 3 Amps 250VAC 0.73" x 0.54" x 0.93" 1 10
Pull ChainsPull Chains
• Use for ceiling fixtures, lamps & fans
• Wire leads #18 AWG, 6”stripped wire
• Push-in connectors for #18 AWG wire
• 13/32” diameter mounting hole
Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5
Cat. Fig. Function Color Poles Terminal No. of Dimensions Bag Master
No. Type Terminals Rating L” x W” x H” Qty Bag
70010 1 On-Off Brass SPST 6" Leads N/A 6 Amps 125VAC 1.25" x 0.825" x 0.625" 1 10
3 Amps 250VAC
70011 1 On-Off Brass SPST 6" Leads N/A 6 Amps 125VAC 1.25" x 0.825" x 0.625" 100 —-
3 Amps 250VAC
70020 1 On-Off Nickel SPST 6" Leads N/A 6 Amps 125VAC 1.25" x 0.825" x 0.625" 1 10
3 Amps 250VAC
6 Amps 125VAC
70023 2 All Angle Nickel SPST 6" Leads N/A 3 Amps 250VAC 2.52" x 1.50" x 0.50" 1 10
Off-On
6 Amps 125VAC
2-Speed
70045 3 Off-On-On Brass SPDT Push in 3 3 Amps 250VAC 1.71" x 1.23" x 0.72" 1 10
70025 4 Off-On(A)-On(B)- Brass SPTT 6" Leads N/A 6 Amps 125VAC 1.25" x 1.00" x 0.625" 1 10
On(A+B)
3 Amps 250VAC
70040 5 Off-On(A)-On(B)- Brass SPTT Push in 4 6 Amps 125VAC 1.50" x 1.25" x 0.75" 1 10 74
3 Amps 250VAC
On(A+B)
