Non-Metallic Toggle Switches
Non-Metallic Toggle Switches
Fig. 1 Fig. 2 Fig. 3
• Double Insulated with Internal O-Ring for
Moisture and Dust Resistance
• 1/2” Mounting Hole
• Dielectric Strength: 1500V
• Insulation Resistance: 500V
• ( ) = Momentary

Cat. Fig. Poles Function Terminal No. of Load Dimensions Bag Master Morris Products Line
No. Type Terminals Rating L” x W” x H” Qty Bag ELECTRICAL
70120 1 SPST On-Off Screw 2 20A 125VAC 1.37" x 0.76" x 0.94" 1 10
10A 277VAC
Momentary
70125 2 SPDT (On)-Off-(On) Quick Connect 3 20A 125VAC 1.37" x 0.76" x 0.94" 1 10
10A 277VAC
Spade
Momentary
70127 3 DPDT (On)-Off-(On) Quick Connect 6 20A 125VAC 1.37" x 0.76" x 0.94" 1 10
10A 277VAC
Spade
ELECTRICAL
Heavy Duty Momentary Contact Toggle SwitchesHeavy Duty Momentary Contact Toggle Switches
• Motor Control & Tool Applications • Mechanical Life Cycles: 100,000
• Solid Brass or Nickel Plated Bushings • 32°F to 185°F
• 1/2" Mounting Hole • ( ) = Momentary
• Dielectric Strength: 1500V Fig. 1
Cat. Fig. Poles Function Terminal No. of Standard Motor Dimensions Bag Master Toggle Switches
No. Type Terminals Load Rating Load Rating L” x W” x H” Qty Bag
Single pole Single throw
20A 125VAC
Momentary 20A 125VAC
70250 1 SPST Screw 2 10A 250VAC 1.13" x 0.57" x 0.61" 1 10
(On)-Off 10A 277VAC
3/4HP 125-250VAC Fig. 2
20A 125VAC
Momentary 20A 125VAC
70252 1 SPST Screw 2 10A 250VAC 1.13" x 0.57" x 0.61" 1 10
On-(Off) 10A 277VAC
3/4HP 125-250VAC
double pole Single throw
20A 125VAC
Momentary 20A 125VAC
70260 2 DPST Screw 4 10A 250VAC 1.30" x 0.76" x 0.80" 1 10
On-(Off) 10A 277VAC
1-1/2HP 125/250VAC Fig. 3
20A 125VAC
Momentary 20A 125VAC
70262 2 DPST Screw 4 10A 277VAC 1.30" x 0.76" x 0.80" 1 10
(On)-Off 10A 277VAC
1-1/2HP 125-250VAC
Single pole Double throw
20A 125VAC
Momentary 20A 125VAC
70270 3 SPDT Screw 3 10A 250VAC 1.13" x 0.63" x 0.70" 1 10
On-Off-(On) 10A 277VAC Fig. 4
3/4HP 125/250VAC
20A 125VAC
Momentary 20A 125VAC
70280 3 SPDT Screw 3 10A 250VAC 1.13" x 0.63" x 0.70" 1 10
(On)-Off-(On) 10A 277VAC
3/4 HP 125-250VAC
double pole Double throw
20A 125VAC
20A 125VAC
70290 4 DPDT (On)-Off-On Screw 6 10A 250VAC 1.32" x 0.75" x 0.86" 1 10
10A 277VAC Fig. 5
1-1/2 HP 125-250VAC
Quick 20A 125VAC
Momentary 20A 125VAC
70299 5 DPDT Connect 6 10A 250VAC 1.30" x 0.76" x 0.86" 1 10
(On)-Off-(On) 10A 277VAC
Spade 1-1/2 HP 125-250VAC
20A 125VAC
Momentary 20A 125VAC
70300 6 DPDT Screw 6 10A 250VAC 1.30" x 0.76" x 0.86" 1 10
(On)-Off-(On) 10A 277VAC
1-1/2 HP 125-250VAC
20A 125VAC Fig. 6
Momentary 20A 125VAC
70135 6 DPDT Screw 6 10A 250VAC 1.30" x 0.76" x 0.86" 1 10
(On)-On 10A 277VAC
1-1/2 HP 125-250VAC
AccessoriesAccessories
RUBBER COVER AND NUT RUBBER COVER
For Toggle Switches For Push Button Switches
• Protects switches from moisture, • Clear Cover
dirt, salt & spray • Protects switches from moisture, Toggle Switch Indicator Plate
• Built-in nut base dirt, salt & spray • Accessory to indicate On-Off
• Fits Standard Toggles • Fits Standard Push Switch • Fits Standard Toggle Switch
Cat. Bag Cat. Bag Cat. Bag
No. Qty No. Qty No. Qty
70240 10 70243 10 70246 100
70241 100
72
