in  whiskerlike crystal growth. Some examples of these different forms  are shown in PLATE 20.
          Even on the same object, well-formed crystals may display a variety of  crystalline habits. On the
          cased Greek bronze mirror discussed in CHAPTER  1, for example (see  CHAPTER  1, FIGURE 1.2),
          crystals  had  signs of elongation  that were  optically positive or optically negative  (Scott  1991).
          Fibrous  malachite, which has  been found growing as curly,  fiberlike  crystals  on bronze  antiq­
          uities  (Scott 1991), has  been observed  to consist  of  parallel aggregates of finely elongated  mala­
          chite crystals,  as shown in PLATES  21 and  22.


          Malachite as a pigment   There  is no evidence  that malachite  or azurite  was used  as pig­
                                   ment  for  Paleolithic rock  art  (Ucko and  Rosenfeld  1967).  The
          minerals,  however, were used extensively for painting in many different media from antiquity
          until relatively recently.
              Malachite and azurite must be ground quite coarsely to retain a good color for pigment  use;
          the minerals become progressively paler  as the particle size is reduced. Malachite is most  effec­
          tive  as  a pigment in tempera. Although it is a bright green,  malachite  covers poorly in oil and
          not very well in watercolor. Gettens and Fitzhugh (1966) describe the color, reflectance  spectra,
          infrared  data, notable  occurrences in paintings, and other  characteristics  of  malachite used as a
          pigment. Art  and  Archaeology Technical Abstracts  {AAT  A) 4  provides more than five hundred  ref­
          erences to the identification of  malachite in paintings, especially in Asia, where its use in Japan,
          China, and Korea has  been  extensive.


          Malachite in bronze patinas  Although malachite  is only a minor constituent  of patinas that
                                   develop on exposed bronze  objects, it can be a significant com­
          ponent  of patinas that  develop  during the corrosion of copper alloys buried in the  soil,  where
          the  first product to form  adjacent to the metal is cuprite; malachite usually forms  over this ini­
          tial  cuprite layer. The uniform growth of this corrosion accounts for the  attractive patina seen
          on  many bronze  antiquities.
              The  natural transition of metal to cuprite  to malachite  is very difficult  to replicate in  the
          laboratory. In fact, most of the  recipes for producing artificial  green  patinas on copper alloys,
          such  as those compiled by Hughes and Rowe  (1982), do not result in malachite formation over
          a cuprite  layer.  Consequently,  the  existence of this type of corrosion, supported  by analytical
          and metallographic studies, is a good indication of the authenticity of an artifact.
                                 I  BANDING   A striking  feature  sometimes  seen in polished
          sections of corroded  bronze  antiquities is a corrosion  crust with  multiple, alternating  layers
          of  malachite  and  cuprite.  This  structure  is reminiscent  of Liesegang  phenomena  described
          in  CHAPTER 2.
              The processes behind the banding of  malachite with cuprite were explored experimentally
          by  Krishnan and  colleagues (i982), who examined  the  anomalous stratification of copper  car-



                         C H A P T E R  T H R E E
                         106
