P. 128

to  one  of the  copper  trihydroxychlorides.  10  This undesirable  color  change was  observed  on
          the fourteenth- to  fifteenth-century  wall paintings depicting San Antonio Abate in the church
          of  San  Pietro  at  Quaracchi,  near  Florence,  Italy.  Rosi  (i987)  reports  the  harmful  effects  that
          occurred with this treatment during the restoration of a pietà by Florentine artist Masolino da
          Panicale  (i383-i440?), who painted this work around 1425 for the baptistry of the Collegiata at
          Empoli. After  the  final barium hydroxide solution was applied, the green degradation  products
          of  azurite  changed  to  a  dark  blue;  after  two years,  this  blue  changed  to  green  again. This
          demonstrates that the conservation treatment had created chemical alterations and that some of
          these alterations were  unstable.
              At  first  it was thought that the treatment had changed the green degradation product (a cop­
          per trihydroxychloride) back to blue azurite, but Dei  and coworkers show that a different reac­
          tion was occurring. The extremely high pH of the barium hydroxide treatment had transformed
          the basic chloride to spertiniite, Cu(OH) 2 , a highly unstable  compound that underwent further
          reaction with chloride-containing water to become a basic chloride again. Dei's group attributes
          this chloride to paratacamite,  but it probably needs to be reassigned  to clinoatacamite.
              Azurite and malachite pigments  are  also sometimes  altered by this conservation  treatment
          to  black tenorite, CuO, again because of the high pH of the barium hydroxide solution.


       F O R M A T I O N  OF  C O P P E R  C A R B O N A T E S  IN  S O L U T I O N
          Malachite  and  azurite  are  precipitated from  copper (II)  sulfate  solutions—the  most common
          solution in which copper is simply dissolved—and complex salts of  copper (II)  by reaction with
          bicarbonate ions (Lindgren 1933). They may also be produced directly from  the reaction of cop­
                                              I
          per (I)  oxide with carbon dioxide and water. f azurite is hydrated or exposed  to an  atmosphere
          deficient in carbon  dioxide, it is gradually converted  to  malachite  (Garrels  and  Christ 1965).
          Chalconatronite may be formed by direct precipitation from  saturated  solutions of the  highly
          soluble Na 2 Cu(C0 3 ) 2 complex. The presence of this sodium-copper carbonate  prevents the pre­
          cipitation of malachite, creating instead an alteration of the reaction process from  malachite to
          chalconatronite  (Applebey and Lane  1918).
              The  Pourbaix  diagrams  for  the  copper-water-oxygen-carbon  dioxide system illustrate
          the conversion of azurite to malachite in carbon dioxide-poor atmospheres. Azurite does not
          appear on these diagrams until the carbon dioxide level reaches  4400  ppm, whereas malachite
          is  present at a carbon dioxide level of 44  ppm. With  increasing carbon dioxide concentration,
          malachite stability increases at the expense of tenorite and cuprite at higher pH  values. The cop­
                                                                    I
          per solubility in this system is limited by the precipitation of malachite. f chloride and  sulfate
          ions  are  absent from  the solution, then malachite is the phase that limits  copper  solubility. In
          solutions containing sulfate and carbonate  ions, antlerite and brochantite limit the solubility  of
          copper  at low  pH values (Mann and Deutscher  1977).




                                                     BASI C  C O P P E R  CARBONATE S
                                                                     111
