FOLLY
Design Process
Scanned drawing
Or
CADWORK
ELEVATION SECTION
CADWORK NIK FARZANA
“We were given a task to trace our previous folly project from semester 1 using softwares
like AutoCad. I was not looking forward to it because I have tried using AutoCad before
and I struggled a lot, even to just make a straight line. From my scanned drawings, I had to
learn how to scale my drawings so that they are in the right scale. Then, I simply used the
pen tool to trace over my drawings which I found to be really easy and satisfying. I still
need to master the weight line of the drawings because at the end, it doesn’t show which
part of the drawings are nearer or further. Tracing drawings was not the only skills I learned,
it was to create a title block from scratch which I did by utilizing rectangle tools and offset
tools.”
PLAN
42
