Page 224 - CATALOGUE (32)
P. 224
203 PL3628 PL6536 204
PALETTE IN PL 28 21 36 19 36 28 65 PALETTE IN PL
28
Ⅲ Ⅲ
FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION
PL PENDANT LIGHTING 3628 1000mmX35mmX28mm AP ALUMINIUM PROFILE PT PENDANT PL PENDANT LIGHTING 6536 1000mmX65mmX36mm AP ALUMINIUM PROFILE PT PENDANT
SYSTEM SYSTEM
PC PC COVER RS RECESSED PC PC COVER RS RECESSED
S STRING EDA END CAPS (ALUMINIUM)
EDA END CAPS (ALUMINIUM) EDW END CAPS (SCREWS)
EDW END CAPS (SCREWS) EXAMPLE: PL6536-1000mmX65mmX36mm-RS
EXAMPLE: PL3628-1000mmX35mmX28mm-RS
PL6532A PL9032A
65
90
32
12.9 24
32 25.4
50 75
Ⅲ Ⅲ
FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION
FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION
PL PENDANT LIGHTING 6532A 1000mmX65mmX32mm AP ALUMINIUM PROFILE RS RECESSED PL PENDANT LIGHTING 9032A 1000mmX90mmX32mm AP ALUMINIUM PROFILE PT PENDANT
SYSTEM
SYSTEM PC PC COVER RS RECESSED
PC PC COVER
EDP END CAPS (PLASTIC) EDA END CAPS (ALUMINIUM)
EDW END CAPS (SCREWS) EDW END CAPS (SCREWS)
EXAMPLE: PL6532A-1000mmX65mmX32mm-RS EXAMPLE: PL9032A-1000mmX90mmX32mm-PT
PL6532B PL9032B
65
90
24.6
32 32 24.6
35
55
50 70
Ⅲ Ⅲ
FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION
PL PENDANT LIGHTING 6532B 1000mm X 65mm X 32mm AP ALUMINIUM PROFILE RS RECESSED PL PENDANT LIGHTING 9032B 1000mmX90mmX32mm AP ALUMINIUM PROFILE PT PENDANT
SYSTEM SYSTEM
PC PC COVER PC PC COVER RS RECESSED
EDA END CAPS (ALUMINIUM) EDA END CAPS (ALUMINIUM)
EDW END CAPS (SCREWS) EDW END CAPS (SCREWS)
EXAMPLE: PL6532B-1000mmX65mmX32mm-RS EXAMPLE: PL9032B-1000mmX90mmX32mm-PT
