Pulling Device with Hydraulic Cylinder,
BMW E39

Suitable for BMW E39 (5 Series) Limousine and Touring rear subframe.
The pulling device KL-0515-50 enables the quick and safe removal and installation
of the silentblocs at the rear subframe. Using this tool, the removal of the rear
KL-0515-500
subframe from the vehicle is no longer necessary.
KL-0515-5000
Scope of Delivery:
KL-0515-50 Pulling Device with Hydraulic Cylinder, BMW E39
Part No. Description Qty
KL-0515-500 Pulling Device without Hydraulic Cylinder, BMW E39 1
KL-0040-2500 Hydraulic Cylinder, 17t 1
KL-0040-2590 Safety Belt for Hydr. Cylinder KL-0040-2500 1

Scope of Delivery:
KL-0515-500 Pulling Device without Hydraulic Cylinder, BMW E39
4
Part No. Description Qty
KL-0041-3801 Bridge 1
KL-0515-5002 Adaptor, M42x2 to M34x1.5 1
KL-0040-2545-1 Pull Spindle, M18 1
KL-0040-2545-3 Shoulder Nut, M18 1
KL-0515-5000 Hook/Pressure Piece Set 1

Scope of Delivery:
KL-0515-5000 Hook/Pressure Piece Set
Part No. Description Qty
KL-0515-5003 Hook (1 pc) with clamp 2
KL-0515-5004 Pressure Piece (extraction) 1
KL-0515-5005 Pressure Piece (insertion) 1
KL-0515-5006 Support Sleeve (insertion) 1

KL-0515-501 KL-0515-501
Upgrade Kit for BMW X5

Specially designed for BMW X5.
Used in conjunction with the pulling device KL-0515-50, the kit allows for the
removal and replacement of the silentblocs at the rear subframe.

Scope of Delivery:
KL-0515-501 Upgrade Kit for BMW X5
Part No. Description Qty
KL-0515-5011 Pressure Piece (extraction) 1
KL-0515-5012 Support Sleeve (insertion) 1
