Page 126 - Donaldson - Exhaust product guide for medium and heavy-duty vehicles and equipment

Truck Engine Muffler Application
TRUCK ENGINE APPLICATION Engine Make & Model Engine H.P. Inlet Body Outlet Inlet Body Outlet Backpressure 4 M110311 Inlet dimension is OD

Muffler Dimensions
Exhaust System
inches of Muffler
mm
inches
Configuration
Notes
H 2 0 Style & Part No.
Hg
102

4.0
26
1.9
4.0
102
279
11.0

11.0
4.0
2.3
31
4.0
102 254x381 102
4
M120367 Aftermarket, shorter than OE
1.1
11.0
127
M110014 OE replacement
279
5.0
4
5.0
15
127
10x15
5.0
5.0
M120366 OE replacement
4.0 10x15 4.0 102 279 102 1.7 23 4 M111025 Inlet & outlet dimension is OD
127 254x381 127
4
1.2
16
5.0 10x15 5.0 127 254x381 127 1.9 26 4 M120417 Aftermarket, shorter than OE
ENDT865 325 5.0 11.0 5.0 127 279 127 2.6 36 4 M110014 OE replacement
5.0 10x15 5.0 127 254x381 127 2.8 38 4 M120366 OE replacement
E7 300 to 350 4.0 10.0 4.0 102 254 102 2.7 36 4 M100052
4.0 11.0 4.0 102 279 102 2.2 30 4 M110112
4.0 11.0 4.0 102 279 102 2.2 30 4 M110148
4.0 11.0 4.0 102 279 102 2.2 30 4 M110311 Inlet dimension is OD
4.0 11.0 4.0 102 279 102 1.9 26 4 M111025 Inlet & outlet dimension is OD
4.0 10x15 4.0 102 254x381 102 2.6 35 4 M120367 Aftermarket, shorter than OE
5.0 11.0 5.0 127 279 127 1.3 17 4 M110014 OE replacement
5.0 10x15 5.0 127 254x381 127 1.3 18 4 M120366 OE replacement
5.0 10x15 5.0 127 254x381 127 2.1 29 4 M120417 Aftermarket, shorter than OE
E6 350 5.0 10x15 5.0 127 254x381 127 2.1 29 6 M120418 For off-hwy, shorter than OE
ENDT673 225 4.0 10.0 4.0 102 254 102 2.2 30 6 M100572
4.0 11.0 4.0 102 279 102 1.7 24 6 M111026 Outlet dimension is OD
5.0 10x15 5.0 127 254x381 127 1.1 15 6 M120418 For off-hwy, shorter than OE
ENDT675 235 4.0 10.0 4.0 102 254 102 2.4 33 6 M100572
4.0 11.0 4.0 102 279 102 1.9 26 6 M111026 Outlet dimension is OD
5.0 10x15 5.0 127 254x381 127 1.2 17 6 M120418 For off-hwy, shorter than OE
ENDT865 325 5.0 10x15 5.0 127 254x381 127 2.9 39 6 M120418 For off-hwy, shorter than OE

E7 300 4.0 10.0 4.0 102 254 102 2.7 37 6 M100572
4.0 11.0 4.0 102 279 102 2.1 29 6 M111026 Outlet dimension is OD
5.0 10x15 5.0 127 254x381 127 1.4 19 6 M120418 For off-hwy, shorter than OE
E7 350 4.0 11.0 4.0 102 279 102 2.4 33 6 M111026 Outlet dimension is OD
5.0 10x15 5.0 127 254x381 127 1.6 21 6 M120418 For off-hwy, shorter than OE
E6 350 4.0 10x15 5.0 102 254x381 127 2.4 32 3 M120566 OE replacement
5.0 10x15 5.0 127 254x381 127 2.6 36 3 M120235 OE replacement
ENDT673 225 4.0 11.0 4.0 102 279 102 2.4 32 3 M110479
4.0 11.0 4.0 102 279 102 2.2 30 3 M110674 Band clamp on inlet
4.0 11.0 102 279 2.1 29 3 M111024 Outlet has down spout
5.0 10x15 5.0 127 254x381 127 1.4 19 3 M120235 OE replacement
ENDT675 235 4.0 11.0 4.0 102 279 102 2.6 35 3 M110479
4.0 11.0 4.0 102 279 102 2.4 32 3 M110674 Band clamp on inlet
4.0 11.0 102 279 2.3 31 3 M111024 Outlet has down spout
5.0 10x15 5.0 127 254x381 127 1.5 21 3 M120235 OE replacement
4.0 10x15 5.0 102 254x381 127 1.4 19 3 M120566 OE replacement
E7 300 to 350 4.0 11.0 102 279 3.0 40 3 M111024 Outlet has down spout
4.0 10x15 5.0 102 254x381 127 1.8 24 3 M120566 OE replacement
5.0 10x15 5.0 127 254x381 127 2.0 27 2 M120235 OE replacement
