National Electrical Price Guide

Assemblies
Feeder EMT & Wire St Set Screw Coup, Strap & Power Shot 4" EMT w/Pull Wire
Qty Description Labor Cost Retail
1 4" 1 Hole Steel Strap .06 2.93 15.19
10 4" EMT 1.40 70.91 138.50
12 Solid Pull Wire .04 .61 2.00
1 1" .300 Drive Pin .02 .07 .30
1 Red .25 Caliber Load .02 .11 .31
1 4" EMT Steel Set Screw Coup .20 4.51 54.50
1.74 $79.14 $210.80
St Set Screw Coup, Strap, Screw & Anchor
Feeder EMT & Wire St Set Screw Coup, Strap, Screw & 3/4" EMT 2#6, 1#10
Anchor
Qty Description Labor Cost Retail
10 3/4" EMT .30 6.82 12.35
23 #6 THHN Stranded Copper .16 8.51 27.19
12 #10 THHN Solid Copper .06 1.72 5.30
1 Average Fastener .01 .18 .40
1 8-10 x 7/8" Bantam Screw Anchor .06 .03 .07
1 3/4" EMT 1 Hole Steel Strap .03 .08 .50
1 3/4" EMT Steel Set Screw Coup .03 .23 2.60
.65 $17.56 $48.42
Feeder EMT & Wire St Set Screw Coup, Strap, Screw & 3/4" EMT 2#8, 1#10
Anchor
Qty Description Labor Cost Retail
10 3/4" EMT .30 6.82 12.35
12 #10 THHN Solid Copper .06 1.72 5.30
23 #8 THHN Stranded Copper .14 5.53 17.74
1 Average Fastener .01 .18 .40
1 8-10 x 7/8" Bantam Screw Anchor .06 .03 .07
1 3/4" EMT Steel Set Screw Coup .03 .23 2.60
1 3/4" EMT 1 Hole Steel Strap .03 .08 .50
.63 $14.59 $38.97
Feeder EMT & Wire St Set Screw Coup, Strap, Screw & 3/4" EMT 3#6
Anchor
Qty Description Labor Cost Retail
10 3/4" EMT .30 6.82 12.35
35 #6 THHN Stranded Copper .25 12.95 41.38
1 Average Fastener .01 .18 .40
1 8-10 x 7/8" Bantam Screw Anchor .06 .03 .07
1 3/4" EMT Steel Set Screw Coup .03 .23 2.60
1 3/4" EMT 1 Hole Steel Strap .03 .08 .50
.68 $20.28 $57.30
Feeder EMT & Wire St Set Screw Coup, Strap, Screw & 3/4" EMT 3#6, 1#10
Anchor
Qty Description Labor Cost Retail
10 3/4" EMT .30 6.82 12.35
12 #10 THHN Solid Copper .06 1.72 5.30
35 #6 THHN Stranded Copper .25 12.95 41.38
1 Average Fastener .01 .18 .40
1 8-10 x 7/8" Bantam Screw Anchor .06 .03 .07
1 3/4" EMT 1 Hole Steel Strap .03 .08 .50
1 3/4" EMT Steel Set Screw Coup .03 .23 2.60
.74 $22.00 $62.60

ASSEMBLIES CONTAINING CONDUIT ARE BASED ON 10' LENGTHS
COST COLUMN IS A NATIONAL AVERAGE AND SHOULD BE VERIFIED FOR YOUR AREA
