General requirements
Inspection devices/Holding magnets and small magnets

Telescopic inspection mirrors

Application: Execution: ƒ Ident. No. 270–280: Round mirror
For inspecting partly concealed areas. ƒ Ident. No. 270: ƒ Ident. No. 280–290: Plastic-coated metal handle
ƒ Chrome-plated metal handle ƒ Ident. No. 290: Square mirror
ƒ With attachment clip

Ident. No. 270 Ident. No. 280 Ident. No. 290
Ø of mirror (mm) 30 50 43
Max. extension length (mm) 520 730 720
280
290
Ident. No.
270
52995... Unit price, € O. R. O. R. O. R.
Prod. Gr. 598
Inspection set
Modular system
Application: scope of supply and services:
For all inspection tasks. 2 mirrors (round 60 mm, rectangular 65 x 43 mm),
telescopic handle, LED inspection lamp, magnetic
Execution: attachment, batteries
ƒ In case with impact-resistant foam inlay
Ø of mirror (mm) 60
Width of mirror (mm) 43
Mirror height (mm) 65
Max. extension length (mm) 600
500
Ident. No.
52995... Set price, € O. R.
Prod. Gr. 598

Flat magnetic grips
General tools
With threaded bush
Application: ƒ Surface galvanised
Auxiliary materials with universal application during ƒ Magnetic shielding
clamping, assembling, lifting and welding operations, ƒ With threaded bush
and for installing in devices etc.
ƒ Operating temperature up to 100°C
Execution:
ƒ With hard ferrite core

Outer Ø (mm) 10 13 16 20 25 32 40 50 63 80 100
Height (mm) 11.5 11.5 11.5 13 15 15 18 22 30 34 43
Height of the base (mm) 4.5 4.5 4.5 6 7 7 8 10 14 18 20
Adherence strength (N) 5 12 30 40 49 90 130 220 300 550 900
Thread dimension M3 M3 M3 M3 M4 M4 M5 M6 M8 M10 M12
Thread length (mm) 7 7 7 7 8 8 10 12 16 16 16
510
560
550
570
590
600
Ident. No.
580
500
530
540
51145... Unit price, € O. R. O. R. 520 O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R.
O. R.
Prod. Gr. 591
Flat magnetic grips
With bore hole and countersink
Application: ƒ Magnetic shielding
Auxiliary materials with universal application during ƒ With bore hole and countersink
clamping, assembling, lifting and welding operations, ƒ Operating temperature up to 100°C
and for installing in devices etc.
Advantage:
Execution: ƒ Fastening option from inside with a screw
ƒ With hard ferrite core
ƒ Surface galvanised
