General requirements
Holding magnets and small magnets

Outer Ø (mm) 16 20 25 32 40 50 63 80
Height (mm) 4.5 6 7 7 8 10.5 14 18
Bore Ø (mm) 3.5 4.2 5.5 5.5 5.5 6.5 6.5 6.5
Adherence strength (N) 30 40 49 90 130 180 290 540
720
770
750
740
760
730
790
780
Ident. No.
51146... Unit price, € O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R.
Prod. Gr. 591
Magnetic bar grips
round, with an AlNiCo core
Application: ƒ Magnet encased in steel
Auxiliary materials with universal application during ƒ Operating temperature up to 450°C
clamping, assembling, lifting and welding operations, ƒ Fastening option: Press in, shrink or glue in place
and for installing in devices etc.
Advantage:
Execution: ƒ Smooth, with h6 fit tolerance
ƒ With AlNiCo core
Outer Ø (mm) 6 8 10 13 16 20 25 32 40 50
Height (mm) 10 12 16 18 20 25 30 35 45 50
Adherence strength (N) 6 10 14 27 36 72 90 100 130 200
520
510
Ident. No.
590
560
570
580
530
540
550
51148... Unit price, € 500 O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R.
O. R.
Prod. Gr. 591
Magnetic bar grips
round, with an AlNiCo core
Application: ƒ Magnet encased in steel
Auxiliary materials with universal application during ƒ Operating temperature up to 450°C
clamping, assembling, lifting and welding operations, ƒ With female thread
and for installing in devices etc.
ƒ Fastening option: Screws
Execution:
ƒ With AlNiCo core
Outer Ø (mm) 6 7 10 13 16 20 25 32
Height (mm) 20 20 20 20 20 25 35 40
Adherence strength (N) 1.7 4 8.5 12 20 50 115 200
Thread dimension M3 M3 M4 M4 M4 M6 M6 M8 General tools
Thread length (mm) 5 5 7 7 5 7 9 9
870
860
850
830
840
820
800
Ident. No.
810
51150... Unit price, € O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R.
Prod. Gr. 591
Magnetic grips
Application: Advantage:
Auxiliary materials with universal application during ƒ Smooth, with h6 fit tolerance
clamping, assembling, lifting and welding operations, ƒ Ident. No. 500–560: With neodymium core for
and for installing in devices etc. approx. 5x adhesive force compared to conven-
Execution: tional flat grips
ƒ Magnet encased in brass ƒ Ident. No. 700–760: With samarium cobalt core
for approx. 5x adhesive force compared to conven-
ƒ Fastening option: Press in, shrink or glue in place tional flat grips
Outer Ø (mm) 6 8 10 13 16 20 25
Height (mm) 20 20 20 20 20 25 35
Adherence strength (N) 7 12 45 70 150 300 500
550
560
540
530
520
510
500
Ident. No.
51149... Operating temperature Unit price, € O. R. O. R. O. R. O. R. O. R. O. R. O. R.
up to 100°C
750
760
700
710
720
730
740
Ident. No.
51149... Operating temperature Unit price, € O. R. O. R. O. R. O. R. O. R. O. R. O. R.
up to 200°C
Prod. Gr. 591
