Screwdrivers
Socket spanner 1/4 inch

Actuating tool DIN 3120
1/4” square drive 6.3 DIN 3120

Application: Technical Data:
T-handle for manual socket wrench inserts and ƒ Tip size: 1/4 inch
connection parts ƒ Surface: Chrome-plated
ƒ Material: Chrome-vanadium steel
Execution:
ƒ Movable sliding head
Length (mm)
010
Ident. No.
58185... 115 Unit price, € O. R.
Prod. Gr. 582
Socket spanner bit, short and long
hexagon, 1/4” square drive 6.3 DIN 3120 DIN 3124

Advantage: Technical Data:
ƒ Optimum force transmission thanks to special ƒ Drive: 1/4 inch
profile ƒ Tip profile type: Special profile
ƒ Bolt and nut are not damaged ƒ Surface: Chrome-plated
ƒ Material: Chrome-vanadium steel
ƒ Higher torques possible
No. 58030
Standard Long version Standard Long version
version version
Length (mm) 25 50 Length (mm) 25 50
Width across flats Outer Ø (mm) 58030... 58042... Width across flats Outer Ø (mm) 58030... 58042...
Ident. No. Ident. No. Ident. No. Ident. No.
4 mm 11 040 O. R. 040 O. R. 9 mm 13 090 O. R. 090 O. R.
4.5 mm 11 045 O. R. 045 O. R. 10 mm 14 100 O. R. 100 O. R.
5 mm 11 050 O. R. 050 O. R. 11 mm 16 110 O. R. 110 O. R.
5.5 mm 11 055 O. R. 055 O. R. 12 mm 17 120 O. R. 120 O. R.
6 mm 11 060 O. R. 060 O. R. 13 mm 18 130 O. R. 130 O. R.
7 mm 11 070 O. R. 070 O. R. 14 mm 20 140 O. R. 140 O. R.
8 mm 12 080 O. R. 080 O. R. Unit price, €
Prod. Gr. 582
Socket wrench insert
For external TORX screws, 1/4” square drive 6.3 DIN 3120 DIN 3120
General tools

Execution:
ƒ Polished Technical Data:
ƒ Knurled ƒ Drive: 1/4 inch
Advantage: ƒ Surface: Chrome-plated
ƒ Material: Chrome-vanadium steel
ƒ Secure handling thanks to non-slip knurling
Tip size E4 E5 E6 E7 E8 E10
060
040
070
080
050
Ident. No.
100
58057... Unit price, € O. R. O. R. O. R. O. R. O. R. O. R.
Prod. Gr. 582
Screwdriver bit DIN 3120
For slotted screws, 1/4” square drive 6.3 DIN 3120
Execution: Technical Data:
ƒ Burnished tips ƒ Drive: 1/4 inch
ƒ Surface: Chrome-plated
Advantage: ƒ Material: Chrome-vanadium steel
ƒ Improved resistance to corrosion thanks to
burnishing process
Width of cutting edge (mm) 4.0 5.5 6.5
Thickness of cutting edge (mm) 0.8 1.0 1.2
080
060
Ident. No.
070
58073... Unit price, € O. R. O. R. O. R.
Prod. Gr. 582
