Screwdrivers
Torque wrenches

Torque wrench with insertion square
With calibration certificate according to DIN EN ISO 6789
Execution: ƒ Rapid securing and opening via the locking ring
ƒ Adjustable torque wrench Advantage:
ƒ For holding square plug-in tools ƒ Robust tubular design Ident. No. 120
ƒ Haptic and acoustic adjustment aid ƒ Plug-in square with locking push button
ƒ Audible and perceptible release when the set value ƒ Viewing window protects scale from damage
is reached
ƒ Dual scale with Nm and lbf.ft. display Technical Data:
ƒ Ergonomically shaped handle with comfortable, ƒ Error limit (%): 3 %
textured surface ƒ With scale: Yes
Min./max. torque measuring range 2.5-25 Nm 10-60 Nm 20-120 Nm 40-200 Nm 60-320 Nm
Scale value (nm) 0.25 0.5 1 1 2
Insert shank square 9 x 12 mm 9 x 12 mm 14 x 18 mm 14 x 18 mm 14 x 18 mm
Length (mm) 258 312 393 488 558
200
025
120
060
320
Ident. No.
52241... Unit price, € O. R. O. R. O. R. O. R. O. R.
Prod. Gr. 5HC
Torque wrench
Application: Advantage:
Suitable for clockwise and anti-clockwise tighten- ƒ The break-over release mechanism makes unin-
ing; when the pre-set torque value is reached, the tended overtightening unlikely
wrench clearly and perceptibly releases and can be 1 2 3
instantly used. scope of supply and services:
Incl. adjustment tool, test certificate according to
Execution: DIN EN 6790
ƒ Lockable torque wrench without scale
ƒ The torque is adjusted using a torque wrench Technical Data:
tester ƒ Insert shank square: 9 x 12 mm
ƒ Permanent adjustment can be performed in-house ƒ Length: 105 mm
ƒ Error limit (%): 6 %
by us (if required, specify the Nm value when ƒ With scale: No
placing your order), or by the customer using a 20°
suitable tester
1
Min./max. torque measuring range 0.4-2 Nm 1-10 Nm
110
Ident. No.
120
52243... Unit price, € O. R. O. R.
Prod. Gr. 5HC
General tools
Torque wrench
Application: ƒ Ident. No. 010–220: ƒ With integrated ratchet function for controlled
For controlled clockwise tightening; when the pre- ƒ The torque is adjusted using a torque wrench clockwise rotation
set torque value is reached, the wrench releases tester
and can be instantly used. ƒ Permanent adjustment can be performed Advantage:
in-house by us (if required, specify the Nm value ƒ The patented release system reliably prevents
Execution: when placing your order), or by the customer unwanted overtightening of the screw connection
ƒ High-quality, single-armed torque wrench without using a suitable tester scope of supply and services:
scale ƒ Ident. No. 310–320:
ƒ High-alloy, stainless steel head ƒ Easy-to-read micrometre scale for making Ident. No. 010–220: Incl. adjustment tool
ƒ Anodised aluminium shank adjustments, can be secured against uninten-
tional changes

Ident. No. 010–040 Ident. No. 210–220 Ident. No. 310–320
Tip size 1/4 inch 3/8 inch 1/2 inch 1/4 inch 1/4 inch 1/4 inch 1/4 inch
Min./max. torque measuring
range 3-25 Nm 15-55 Nm 40-125 Nm 1-5 Nm 2-10 Nm 1-5 Nm 2-10 Nm
Length (mm) 216 324 460 185 185 195 195
With scale No No No No No Yes Yes
Error limit (%) (%) 4 4 4 6 6 6 6
220
310
320
210
030
Ident. No.
010
52243... Unit price, € O. R. O. R. 040 O. R. O. R. O. R. O. R.
O. R.
Prod. Gr. 5HC
