Compressed air tools and accessories
Coupling and nipple

Couplings
automatic shut-off, made of brass, e.g. for handheld pneumatic machines, DN 7.2
Application: Execution: ƒ Seal oil-, gasoline- and heat-resistant
For connecting hoses to compressed air tools and ƒ DN 7.2 ƒ Rollers made from stainless steel
compressed air machines. ƒ Automatic shut off ƒ Perbunan (NBR) seal
ƒ Immediate seal, therefore no loss of pressure ƒ Ident. No. 010–030, 110–125: Spring made of
ƒ Not necessary to push back sleeve when coupling V2A steel

Ident. No. 010–030 Ident. No. 060–100 Ident. No. 110–125
Couplings with male thread Couplings with hose connection Couplings with female thread
Version With male With male With male With female With female With female With hose With hose
thread thread thread thread thread thread connection connection
Connection thread G 1/4 inch G 3/8 inch G 1/2 inch G 1/4 inch G 3/8 inch G 1/2 inch - -
Width across flats 21 mm 21 mm 21 mm 21 mm 21 mm 24 mm 21 mm 21 mm
Suitable for hose internal
Ø (mm) - - - - - - 6 8
120
110
125
060
010
020
Ident. No.
030
080
75141... Unit price, € O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R.
Version With hose With hose With hose
connection connection connection
Connection thread - - -
Width across flats 21 mm 21 mm 21 mm
Suitable for hose internal 9 10 13
Ø (mm)
095
100
Ident. No.
75141... Unit price, € 090 O. R. O. R.
O. R.
Prod. group 790
Compressed air plug-in nipple
With G 1/4 inch male thread
Application: Execution:
For connecting the hose, the tool or the machine to ƒ Fits pneumatic couplings no. 75141
the compressed air coupling. ƒ Made of brass
Type With male thread With male thread With male thread
Length (mm) 33 33 35
Connection thread G 1/4 inch G 3/8 inch G 1/2 inch
Thread length (mm) 8 9 10
Width across flats 17 mm 19 mm 24 mm
160
150
Ident. No.
75147... Unit price, € 140 O. R. O. R.
O. R.
Prod. group 790
Compressed air plug-in nipple
With G 1/2 inch female thread
Application: Execution:
For connecting the hose, the tool or the machine to ƒ Fits pneumatic couplings no. 75141
the compressed air coupling. ƒ Made of brass
Type With female thread With female thread With female thread
Length (mm) 33 33 33
Connection thread G 1/4 inch G 3/8 inch G 1/2 inch
Thread length (mm) 10 10 10
Width across flats 17 mm 19 mm 24 mm
180
170
Ident. No.
190
75149... Unit price, € O. R. O. R. O. R.
Prod. group 790
