Drilling tools
Stone drill

Cemented carbide multi-purpose drill bit set for stone drill with straight shank Metal cutting tools
For universal use in stone, tiles, wood and NF metals

Z HA
VHM
2
Application: Advantage:
For drilling and hammer drilling in concrete, ƒ High-quality carbide, ensures a very long service
masonry, brickwork, cement asbestos, lightweight life even when drilling in hard-wearing materials
materials, composite materials, ceramic, tiles, ƒ Broad scope for use thanks to an innovative
wood, plastic, sheet metal and NF metals. cutter design with an active centring section and
Execution: diamond-ground cutter
ƒ Soldered cemented carbide cutting insert with a ƒ Innovative soldering and hardening technologies
extend the service life and reduce vibrations
special centring section, straight shank and two
cutters in a sturdy metal box. ƒ Reinforced core and 4-spiral groove design for
high stability and good chip and sawdust removal
Composition of set 4 x 75/5 x 85/6 x 100/8 x 120
Number of pieces in assortment/set (PCS) 4
Ident. No.
11187... Set price, € 500
O. R.
Prod. group 113
Hammer drill bit, two cutters with SDS shank
For use in stone, concrete, reinforced materials and masonry
Z plus
SDS
VHM
2
Application: ƒ Innovative cutter design with an active centring
For drilling and hammer drilling in concrete, section (from 10 mm diameter) for good centring
reinforced materials, masonry, granite, natural and properties
artificial stone and sand-lime brick. ƒ Innovative soldering and hardening technologies
extend the service life and reduce vibrations
Execution: ƒ 4-spiral groove design allows very good sawdust
ƒ Soldered cemented carbide cutting insert, SDS- removal and minimises the effort required; toothed
plus shank, two cutters cemented carbide guides the dust directly into the
Advantage: spiral and prevents blockage
ƒ High-quality cemented carbide ensures a very long
service life and heat resistance even when drilling
in hard-wearing materials
Cutting edge Ø Chip flute Length (mm) Number of 11190... Cutting edge Ø Chip flute Length (mm) Number of 11190...
(mm) length (mm) cutting edges ID no. (mm) length (mm) cutting edges ID no.
(PCS) (PCS)
4 100 160 2 041 O. R. 14 100 160 2 140 O. R.
5 50 110 2 050 O. R. 14 200 260 2 141 O. R.
5 100 160 2 051 O. R. 14 250 310 2 142 O. R.
6 50 110 2 061 O. R. 14 550 610 2 143 O. R.
6 100 160 2 062 O. R. 15 100 160 2 150 O. R.
6 150 210 2 063 O. R. 15 200 260 2 151 O. R.
6 200 260 2 064 O. R. 16 250 310 2 160 O. R.
7 50 110 2 071 O. R. 16 400 460 2 161 O. R.
8 50 110 2 080 O. R. 16 550 610 2 162 O. R.
8 100 160 2 081 O. R. 16 950 1000 2 166 O. R.
8 150 210 2 082 O. R. 18 150 200 2 180 O. R.
8 200 260 2 083 O. R. 18 400 450 2 181 O. R.
10 50 110 2 100 O. R. 20 150 200 2 200 O. R.
10 100 160 2 101 O. R. 20 400 450 2 201 O. R.
10 150 210 2 102 O. R. 22 200 250 2 220 O. R.
10 200 260 2 103 O. R. 22 400 450 2 221 O. R.
10 400 460 2 104 O. R. 24 200 250 2 240 O. R.
12 100 160 2 120 O. R. 25 200 250 2 250 O. R.
12 150 210 2 121 O. R. 25 400 450 2 251 O. R.
12 200 260 2 122 O. R. 26 400 450 2 261 O. R.
12 400 460 2 123 O. R. Unit price, €
12 950 1000 2 126 O. R.
Prod. group 113
