Drilling tools
Stone drill

Cemented carbide hammer drill bit set SDS-plus
in box
Metal cutting tools
Metal cutting tools
Z SDS
plus
VHM
2
Application: Advantage:
For use in concrete, reinforcement, masonry, gran- ƒ High cemented carbide quality ensures a very long
ite, natural and artificial stone, as well as sand lime, service life and heat resistance even with non-
with turning and hammer drill bit set. wearing materials
Execution: ƒ Innovative cutter design with active centring point
(from diameter of 10 mm) ensures good centring
ƒ Cemented carbide insert, soldered, SDS plus characteristics
shank and two tips in robust metal box ƒ Latest soldering and hardening technology
increases service life and reduces vibrations
Composition of set 5 x 100/6 x 100/8 x 100/
5 x 50/6 x 50/6 x 100/ 10 x 100/12 x 100/
6 x 150/8 x 150/
8 x 50/8 x 100/10 x 100/ 10 x 150/12 x 150/
12 x 100 14 x 150/8 x 200/
10 x 200/12 x 200/14 x 200 Ident. No. 015
Number of pieces in assortment/set (PCS) 7 14
Ident. No.
015
030
11191... Set price, € O. R. O. R.
Prod. group 113

Ident. No. 030

Hammer drill bit, four-cutter with SDS-plus
For use in stone, concrete, reinforced materials and masonry

SDS
Z plus
VHM
4
Application: ƒ Innovative four-cutter design with centring point
For drilling and hammer drilling in concrete, and a specially formed solid carbide cutter ensure
reinforced materials, masonry, granite, natural and an extremely long service life and high drilling
artificial stone and sand-lime brick. rates combined with high centring accuracy. No
jamming when drilling in reinforced concrete
Execution: ƒ Optimised spiral forms ensure low vibration
ƒ Soldered cemented carbide full head, SDS-plus ƒ 4-spiral groove design ensures very good sawdust
shank, two cutters removal and minimises the effort required
Advantage:
ƒ High-quality carbide in a solid head design ensures
a very long service life and heat resistance even
when drilling in hard-wearing materials
Cutting edge Ø Chip flute Length (mm) Number of 11191... Cutting edge Ø Chip flute Length (mm) Number of 11191...
(mm) length (mm) cutting edges ID no. (mm) length (mm) cutting edges ID no.
(PCS) (PCS)
5 50 110 4 050 O. R. 10 100 165 4 101 O. R.
5 100 160 4 051 O. R. 10 150 215 4 102 O. R.
5 150 210 4 052 O. R. 10 200 265 4 103 O. R.
5.5 50 110 4 055 O. R. 10 300 365 4 104 O. R.
5.5 100 160 4 056 O. R. 10 400 465 4 105 O. R.
6 50 115 4 060 O. R. 12 100 165 4 120 O. R.
6 100 165 4 061 O. R. 12 150 215 4 121 O. R.
6 150 215 4 062 O. R. 12 200 265 4 122 O. R.
6 200 265 4 063 O. R. 12 300 365 4 123 O. R.
6.5 50 115 4 065 O. R. 12 400 465 4 124 O. R.
6.5 100 165 4 066 O. R. 14 100 165 4 140 O. R.
6.5 200 265 4 067 O. R. 14 150 215 4 141 O. R.
7 50 115 4 070 O. R. 14 200 265 4 142 O. R.
7 100 165 4 071 O. R. 14 300 365 4 143 O. R.
7 150 215 4 072 O. R. 14 400 465 4 144 O. R.
8 50 115 4 080 O. R. 15 100 165 4 150 O. R.
8 100 165 4 081 O. R. 15 200 265 4 151 O. R.
8 150 215 4 082 O. R. 16 150 215 4 160 O. R.
8 200 265 4 083 O. R. 16 200 265 4 161 O. R.
8 300 365 4 084 O. R. 16 400 465 4 162 O. R.
8 400 465 4 085 O. R. Unit price, €
10 50 115 4 100 O. R.
Prod. group 113
