Pneumatic tools
Compressed Air Fittings Series 320
Coupling materials:
• Brass nickel-plated coupling parts
• Steel nickel-plated locking sleeve
• Valve made of brass and sealings made of nitrile
• Springs and locking balls made of stainless steel
Technical data:
• Flow rate (at 6 bar):2030 l/min
• Temperature:-30°C to +100°C
Couplings, Outside Thread
Technical Data
Art.-No. SW mm Length mm
3926 14 4 20 60
3926 38 4 20 57
3926 12 4 20 52
Article No. Article Description QTY
3926 12 4 COMPRESSED AIR COUPL.ST AR1/2" 1 z
3926 14 4 COMPRESSED AIR COUPL.ST AR1/4" 1 z
3926 38 4 COMPRESSED AIR COUPL.ST AR3/8" 1 z
Plug Nipple, Outside Thread
Technical Data
Art.-No. SW mm Length mm
3926 14 3 14 37
3926 38 3 17 37
3926 12 3 22 43
Article No. Article Description QTY
3926 12 3 PLUG NIPPLE SW22 STEEL AR 1/2" 1
3926 14 3 PLUG NIPPLE SW14 STEEL AR 1/4" 1
3926 38 3 PLUG NIPPLE SW17 STEEL AR 3/8" 1
Couplings, Inside Thread
Technical Data
Art.-No. SW mm Length mm
3927 14 4 20 56
3927 38 4 20 56
3927 12 4 25 56
Article No. Article Description QTY
3927 12 4 COMPRESSED AIR COUPL.ST IR1/2" 1 z
3927 14 4 COMPRESSED AIR COUPL.ST IR1/4" 1 z
3927 38 4 COMPRESSED AIR COUPL.ST IR3/8" 1 z
