Pneumatic tools

Plug Nipple Outside Thread Series 410

Technical Data
Art.-No. SW mm Length mm
3926 14 8 17 41.0
3926 38 8 17 41.0
3926 12 8 22 48.0
3926 34 8 27 52.5

Article No. Article Description QTY
3926 14 8 PLUG NIPPLE 410 AR1/4" 1 ü
3926 38 8 PLUG NIPPLE 410 AR3/8" 1 ü
3926 12 8 PLUG NIPPLE 410 AR 1/2" 1
3926 34 8 PLUG NIPPLE 410 AR3/4" 1 z

Plug Nipple Inside Thread Series 410

Technical Data
Art.-No. SW mm Length mm
3927 14 10 17 36
3927 38 10 20 38
3927 12 10 27 43.5

Article No. Article Description QTY
3927 12 10 PLUG NIPPLE 410 IR1/2" 1 z
3927 14 10 PLUG NIPPLE 410 IR1/4" 1 ü
3927 38 10 PLUG NIPPLE 410 IR3/8" 1 ü

Nozzle Hose Connection Series 410

Technical Data
Art.-No. SW mm
3927 12 8 45
3927 58 8 47.5
3927 34 8 48

Article No. Article Description QTY
3927 12 8 PLUG NIPPLE 410 13MM 1 ü
3927 34 8 PLUG NIPPLE 410 19MM 1 ü
3927 58 8 PLUG NIPPLE 410 16MM 1 ü

Technical data subject to change.
Availability subject to country specific rules and regulations. www.iconridge.com Source: Theo Förch GmbH & Co. KG 605
