Pneumatic tools

Plug Nipple, Inside Thread

Technical Data
Art.-No. SW mm Length mm
3927 14 3 17 39
3927 38 3 19 40
3927 12 3 24 44

Article No. Article Description QTY
3927 12 3 PLUG NIPPLE SW24 STEEL IR 1/2" 1
3927 14 3 PLUG NIPPLE SW17 STEEL IR 1/4" 1
3927 38 3 PLUG NIPPLE SW19 STEEL IR 3/8" 1

Couplings Hose Connection

Technical Data
Art.-No. for hose-Ø mm SW mm Length mm
3928 6 4 6 19 64
3928 8 4 8 19 66
3928 10 4 10 19 67
3928 13 4 13 19 65

Article No. Article Description QTY
3928 6 4 COMPRESSED AIR COUPLING ST 6MM 1 z
3928 8 4 COMPRESSED AIR COUPLING ST 8MM 1 z
3928 10 4 COMPRESSED AIR COUPLING ST10MM 1 z
3928 13 4 COMPRESSED AIR COUPLING ST13MM 1 z

Nozzle Hose Connection

Technical Data
Art.-No. for hose-Ø mm Length mm
3928 6 3 6 48
3928 8 3 8 48
3928 10 3 10 48
3928 13 3 13 48

Article No. Article Description QTY
3928 6 3 NOZZLE STEEL 6MM 1
3928 8 3 NOZZLE STEEL 8MM 1
3928 10 3 NOZZLE STEEL 10MM 1
3928 13 3 NOZZLE STEEL 13MM 1
