Chemical products

Windscreen Adhesives for the direct glazing of windscreens,
side and rear window

Truck - Windscreen Adhesives ASK K107

• Truck windscreen adhesive
• Meets OEM requirements
• Cold curing
• Specially suitable for vehicles with open window joints / UV and
weather resistant
• Can be smoothed easily, high abrasion-proof / low particle
• Long skin formation time makes insertion of very big windscreens
possible
• Working time 20-25 mins.
• Drive away time: from 6 hours
• Cartridge thread: M15x1.5

Article No. Article Description
6600 6135 WSA TRUCKLINE C(310ML) K107
6600 6136 SET WSA-TRUCKLINE C(310ML)K107
6600 18 PK WSA TRUCKLINE K(310ML) K107
6600 6137 WSA TRUCKLINE C(600ML) K107

Contents Art.-No. 6600 6136:
• 2x Art.-No. 6600 6135 cartridge ASK K107 310ml
• 1x Art.-No. 6600 6104 ASK Primer 10ml
• 1x Art.-No. 6600 6109 ASK windscreen bond cleaner R540 20ml
• 2x Art.-No. 6010 0008 ASK-nozzle
• 1x Art.-No. 5413 4 cleaning cloth
Contents Art.-No. 6600 18:
• 12x Art.-No. 6600 6135 cartridge ASK K107 310ml
• 12x Art.-No. 6600 6104 ASK Primer K110 10ml
• 1x Art.-No. 6110 1000 ASK windscreen bond cleaner 500ml
• 12x Art.-No. 6010 0008 ASK-nozzle

ASK - Data Schedule

Characteristics All Seasons All Seasons Clean & Stick Standard Truckline
Speed K113 Clever K103 K106 K105 K107
Product base 1K-PUR 1K-PUR 1K-PUR 1K-PUR 1K-PUR
Processing cold cold cold cold cold
Glazing time max. 15 min max. 15 min max. 15 min max. 20 min max. 25 min
8
8
6
6
Specific resistance (Ohm) ≥10 Ω cm ≥10 Ω cm approx 10 Ω cm approx 10 Ω cm approx 10 Ω cm
6
Optimum high frequency yes yes yes yes yes
performance
Shear modulus ≥ 2,0 MPa ≥ 2,0 MPa > 2,5 MPa approx 2,5 MPa approx 2 MPa
Stability excellent excellent very good very good very good
Ready to drive according 30 min 1 h 1 h 1 h from about 6 h
to US-Norm
50 km/h frontal crash)
without double airbag
With double airbag 30 min 1 h 1 h 2 h from about 6 h
Recommended ambient ≥ +5 °C ≥ +5 °C ≥ +10 °C ≥ +15 °C ≥ +15 °C
temperature for
application
Free of primer and no no yes no no
activating agent

Based on the US standards (50 km/h frontal collision)

Technical data subject to change.
