UTILITY LIGHTS IS Series Utility Lights Features:
Macris also offer the IS Utility range, a product line designed to be extremely scalable and conforms
to a variety of application settings. From surface mounting to drop lighting, the IS Series does it all.
The IS range comes in standard white and is available in five sizes.

• Suited to surface or drop lighting
• Standardised appearance from smallest light to
largest light for visual uniformity.
• 5 models available
• Clean modern style
• Round or rectangular models
• Great for illuminating the interior during night diving
or fishing
• Use around the vessel; illuminate near ladders,
around the galley or cockpit or through the cabin.

IS3 IS15 IS30

IS60 IS120

Specifications
MODEL IS3 IS15 IS30 IS60 IS120
Voltage 12 V DC 12 V DC 12 or 24 V DC 10-30 V DC 10-30 V DC
Power 1.75W 8.5W 18W 34W 64W
Consumption
Fixture Lumens 150+ 800+ 1700+ 3200+ 3200+
Dimensions 50.8mm diameter, 5.9mm high 203.2mm long, 79mm wide, 355.6mm long, 79.3mm wide, 603.2mm long, 182.5mm wide, 1120.7mm long, 182.5mm wide,
5.9mm high 5.9mm high 13.9mm high. 13.9mm high
Housing Impact & UV Impact & UV Impact & UV Impact & UV resistant Impact & UV resistant
resistant acrylic resistant acrylic resistant acrylic acrylic, anodized 6063 acrylic, anodized 6063
aluminum (IS60, IS120 only) aluminum (IS60, IS120 only)
Lens Material: PMMA (acrylic). Average life expectancy 50,000+ hours
Featuring vibration proof, ignition-protected design.
Beam Angle: 120° IP Rating: IP68 Colour: Available in Cool White Install location: Surface (Flush)

AMI Code Supplier Code Description
1262150 IS3 IS3 Courtesy 175W 5cm diam 12V IP68
1262153 IS15 IS15 Utility 8W 20cm 12V IP68
1262154 IS15-24 IS15 Utility 8W 20cm 24V IP68
1262502 IS15BZL Standoff side exit bezel for IS15
1262156 IS30 IS30 Utility 16W 35cm 12V IP68
1262157 IS30-24 IS30 Utility 16W 35cm 24V IP68
1262504 IS30BZL Standoff side exit bezel for IS30
1262159 IS60 IS60 Utility 32W 60cm 10-30V IP68
1262506 IS60BZL Standoff side exit bezel for 60 size
1262162 IS120 IS120 Utility 64W 112cm 10-30V IP68
1262508 IS120BZL Standoff side exit bezel for IS120
