Bill Of Quantity Details

No. Product Description QTY

1 Projector 4000 to 5500 Lumens Projector with WUXGA resolution 2

2 Projector Mount or Projector Lift Projector mount or LCV projector lift to do control with room control AV system 2

3 IP Link AC Power and Device Controller Web-based remote AC power and device control with scheduling,One female Edison AC outlet,One bidirectional RS-232 serial port,One IR port, One contact
closure input for detecting a switch closure,E-mail notification enables proactive support

4 SMP 351 H.264 Streaming Media Processor Process two high resolution AV sources from up to five available input signals Stream and record simultaneously High quality scaling with flexible two- 2
window management Produce MP4 media files that are compatible with virtually any media player. Dual Recording and Streaming with Link License® New
RTMP streaming protocol supports popular third party hosting services

5 Twisted Pair Extender for USB Peripherals Tx & RX Extends USB peripherals up to 1,980 feet (600 meters) through a Gigabit Ethernet network Extends USB peripherals up to 330 feet (100 meters) point-to-
point over one CATx cable Supports USB 2.0 through 1.0 devices with data rates of up to 480 Mbps. Compatible with USB 3.0 devices that can operate at USB
2.0 data rates Choice of rack-mountable and architectural form factors USB switching controller lets you easily create small or large USB switching systems

6 DTP Transmitter for HDMI Tx & Rx Transmits HDMI plus control and analog audio up to 230 feet (70 meters) over a shielded CATx cable Supports computer and video resolutions up to 4K Sup-
ported HDMI specification features include data rates up to 10.2 Gbps, Deep Color up to 12-bit, 3D, HD lossless audio formats, and CEC pass-through HDCP
2.2 compliant Extron XTP DTP 24 shielded twisted pair cable is strongly recommended for optimal performance Compatible with CATx shielded twisted pair
cable .

7 12" Tabletop TouchLink Pro Touchpanel 12” capacitive touchscreen with 1280x800 resolution and 16 million colors Faster processing and more memory Full-motion video preview and monitoring 1
with HDMI and XTP inputs Compatible with all IP Link® Pro control processors PoE+ delivers power and communication over a single Ethernet cable, elimi-
nating the need for a local power supply - Power injector sold separately Built-in speakers provide stereo audio

8 Series/2 Cable Access Enclosure for AV Con- Accommodates one Series/2 AC 100 Series or AC+USB 200 Series Power Module, plus three Retractors, eight AV cables, or three AAP - Architectural Adapter 1
nectivity and AC Power Plates Slim enclosure is ideal for conference tables, desks or study carrels, lecterns, and other work spaces where space is at a premium Patented modular
design for fast assembly and serviceability Retractor bracket, Cable Pass-Through bracket, and AAP bracket included; Retractor modules, cables, and AAP
plates sold separately Retractor Bracket holds three Retractor Series/2 or Retractor Series/2 XL cable retraction modules Connectivity Bracket supports up to
three single-space AAPs

9 Control Processor with IPAD Control Supports TouchLink® Pro touchpanels and eBUS® button panels,Supports secure industry standard communications protocols Supports LinkLicense® Two bi- 1
directional RS-232 serial ports with software handshaking One bidirectional RS-232/RS-422/RS-485 serial port with hardware and software handshaking Two
IR/Serial ports for one-way control of external devices

10 Power Amplifier Reliable 2 x 120 W Class-D amplification optimized for 70/100V high-impedance applications 1

11 Ceiling Speaker Full-range loudspeaker with a single 2.25" (57 mm) driver in a ported enclosure to deliver a 140° conical coverage pattern and clear, intelligible music and 4

speech reproduction for flush-ceiling or pendantmount applications

12 Ceiling Speaker Premier high-performance, extended-range, flush-mount loudspeaker designed for foreground music and speech reproduction in a wide range of installed 2
applications. High output and wide, 160° conical pattern with a frequency range down to 60 Hz.

13 Miscellaneous equipment's for recording 4k HD resolution camera along with recording lights & wireless microphone strictly UHF frequency

14 CENTRAVERSE™ CVG12D 12” (30.5 CM) Cardioid polar pattern with tailored response for speech, Integrated desktop base,Optional Mute Function with LED lighting,12” (30.5 cm) gooseneck Inline 6
GOOSENECK MICROPHONE WITH INTEGRAT- preamp Dual-section gooseneck enables ease of positioning and placement options XLR cable/connection. Plug-and-play solution for minimized setup times
ED DESKTOP BASE AND INLINE PREAMP,

** Kindly Note the above line items are not a complete BOQ the final BOQ will be designed once the details will receive to us , the quantities mentioned are tentative and varies as per the requirement
