Bill Of Quantity Details

No. Product Description QTY

1 LED DISPLAY true 4k 60 inches LED Display True 4k o of resolution 4096 X 2160 p 2

2 Wall Mount Kit For display Super Large Articulating TV Wall Mount, Arms can be extend to 910mm.Max Load Capacity 200lbs(90kg),Extension From 3.8”(97mm) to 2

36”(910mm),Tilt +15°/-5° ,Swivel 180° Horizontal Adjustment,±5°
3 Three Input Multi-Format Switcher with Inte- Transmits DisplayPort, HDMI, or VGA plus control and analog audio up to 230 feet (70 meters) over a shielded CATx cable, Auto-switching be- 2

grated DTP Transmitter and Audio Embedding tween inputs,Supports computer and video resolutions up to 4K,Analog stereo audio embedding, emote powering of DTP receiver

4 DTP Receiver for HDMI - Decorator-Style Wall- Receive HDMI plus control and analog audio up to 230 feet (70 meters) over a shielded CATx cable Supports computer and video resolutions up 2
plate to 4K Extron XTP DTP 24 shielded twisted pair cable is strongly recommended for optimal performance

5 Video Conferencing Brings SIP/H.323 videoconferencing, Skype for Business and Spontania cloud video and web conferencing into a single appliance, Perfect for 1

both single-site and multi-site interactive collaboration, Multi-purpose solution makes it perfect for multiple applications and environments Mul-
ti-source collaboration with simultaneous capture of up to 4 video input sources, f support and maintenance for your collaboration and confer-
encing needs

6 Scaling Presentation Matrix Switcher All in one 8x4 4K matrix switcher, scaler, audio DSP with AEC, audio power amplifier, and control processor Two DTP inputs and six HDMI inputs 1
Two HDMI outputs and two independently scaled DTP outputs 4K matrix switching and scaling with selectable seamless transitions and logo key-
ing Integrated DTP inputs and outputs support transmission of video, control, and audio up to 330 feet (100 meters) over a shielded CATx cable
Advanced Extron Vector™ 4K scaling engine

7 Control Processor with IPAD Control Supports TouchLink® Pro touchpanels and eBUS® button panels, Supports secure industry standard communications protocols Supports Link Li- 1
cense® Two bidirectional RS-232 serial ports with software handshaking One bidirectional RS-232/RS-422/RS-485 serial port with hardware and
software handshaking Two IR/Serial ports for one-way control of external devices

8 12x8 Pro DSP Proc. w/AEC and POTS Eight channels of AEC - acoustic echo cancellation, Eight inputs with Flex Input capability to select between analog or Dante inputs on 1
DMP 128 AT models Dante audio networking provides a wide range of expansion capabilities

9 Power Amplifier Reliable 2 x 120 W Class-D amplification optimized for 70/100V high-impedance applications 1

10 Ceiling Speaker Full-range loudspeaker with a single 2.25" (57 mm) driver in a ported enclosure to deliver a 140° conical coverage pattern and clear, intelligible 4

music and speech reproduction for flush-ceiling or pendant mount applications

11 Ceiling Speaker Premier high-performance, extended-range, flush-mount loudspeaker designed for foreground music and speech reproduction in a wide range 2
of installed applications. High output and wide, 160° conical pattern with a frequency range down to 60 Hz.

12 CENTRAVERSE™ CVG12D 12” (30.5 CM) Cardioid polar pattern with tailored response for speech, Integrated desktop base, Optional Mute Function with LED lighting,12” (30.5 cm) 6
GOOSENECK MICROPHONE WITH INTEGRAT- gooseneck Inline preamp Dual-section gooseneck enables ease of positioning and placement options XLR cable/connection. Plug-and-play solu-
ED DESKTOP BASE AND INLINE PREAMP, tion for minimized setup times

** Kindly Note the above line items are not a complete BOQ the final BOQ will be designed once the details will receive to us , ** The input source device and output source device is on customer requirement and will decide after
mutual discussion. The quantities mentioned in boq will varies as per the customer application.
