Bill Of Quantity Details

No. Product Description QTY

Central Equipment's

15 Modular Power Enclosure for Fibre Optic and Accommodates up to 16 single-slot or eight double-slot multi-function boards, Space-saving design with a compact 3U, rack-mountable enclosure, Modular, 1
Twisted Pair Extenders field-upgradeable, and hot-swappable design Optional redundant power supply Hot-swappable power supplies Exceptional thermal management

16 Video Conferencing Codec for VC live commu- The video conferencing Full HD codec for VC live communication 1

nication

17 Three Input Compact HDCP-Compliant Video HDMI and analog video scaling to HDMI,Auto-switching between inputs, HDMI audio embedding, Selectable output rates from 640x480 to 1920x1200, in- 1
Scaler for operator cluding 1080p/60 and 2K,Advanced scaling engine with 30bit precision processing and motion-adaptive DE interlacing for signals up to 1080i,HDCP compliant

18 Fiber Optic Transmitter for HDMI, Audio, and RS-232 Transmits HDMI video, stereo audio, and RS-232 control signals very long distances over fiber optic cabling HDCP compliant All-digital technology provides 1
pixel-for-pixel performance with signals up to 1920x1200, including HDTV 1080p/60 Integrates easily into a wide range of 4K environments Key Minder con-
tinuously verifies HDCP compliance for quick, reliable switching EDID Minder® automatically manages EDID communication between connected devices

19 Four Window HDCP-Compliant Multi-Window Combines HDMI, 3G-SDI, high resolution RGB, component,S-video, and composite input sources into four windows on a single display ,RGB, HDTV compo- 1
Processor nent video, and HDCP-compliant HDMI output, Key Minder® continuously verifies HDCP compliance for quick, reliable switching ,Selectable output rates from
640x480 to 1920x1200, including HDTV 1080p/60 and 2K ,Graphic Still Store enables use of screen captures or uploaded graphics as background images ,Live
video background from a dedicated HDMI source

20 Operator Monitor Operator monitor to view the remote classroom 1

21 Modular Fiber Optic Matrix Switcher from 8x8 I/O sizes from 8x8 to 32x32,Compatible with all Extron FOX Series transmitters and receivers, peed Switch® Technology provides exceptional switching speed 1
to 32x32 for HDCP-encrypted content. Integrates easily into a wide range of 4K environments, Multimode and single mode I/O boards available,3G-SDI I/O board avail-
able

22 DTP Transmitter for HDMI Tx & Rx Transmits HDMI plus control and analog audio up to 230 feet (70 meters) over a shielded CATx cable Supports computer and video resolutions up to 4K Sup-
ported HDMI specification features include data rates up to 10.2 Gbps, Deep Color up to 12-bit, 3D, HD lossless audio formats, and CEC pass-through HDCP
2.2 compliant Extron XTP DTP 24 shielded twisted pair cable is strongly recommended for optimal performance Compatible with CATx shielded twisted pair
cable .

23 12" Table top Touch Link Pro Touch panel 12” capacitive touchscreen with 1280x800 resolution and 16 million colors Faster processing and more memory Full-motion video preview and monitoring 1
with HDMI and XTP inputs Compatible with all IP Link® Pro control processors PoE+ delivers power and communication over a single Ethernet cable, elimi-
nating the need for a local power supply - Power injector sold separately Built-in speakers provide stereo audio

24 Series/2 Cable Access Enclosure for AV Con- Accommodates one Series/2 AC 100 Series or AC+USB 200 Series Power Module, plus three Retractors, eight AV cables, or three AAP - Architectural Adapter 1
nectivity and AC Power Plates Slim enclosure is ideal for conference tables, desks or study carrels, lecterns, and other work spaces where space is at a premium Patented modular
design for fast assembly and serviceability Retractor bracket, Cable Pass-Through bracket, and AAP bracket included; Retractor modules, cables, and AAP
plates sold separately Retractor Bracket holds three Retractor Series/2 or Retractor Series/2 XL cable retraction modules Connectivity Bracket supports up to
three single-space AAPs

25 Control Processor with IPAD Control Supports TouchLink® Pro touchpanels and eBUS® button panels,Supports secure industry standard communications protocols Supports LinkLicense® Two bi- 1
directional RS-232 serial ports with software handshaking One bidirectional RS-232/RS-422/RS-485 serial port with hardware and software handshaking Two
IR/Serial ports for one-way control of external devices

** Kindly Note the above line items are not a complete BOQ the final BOQ will be designed once the details will receive to us , The quantity mentioned above is tentative and varies on the requirement.
