Bill Of Quantity Details

No. Product Description QTY

Corporate Auditorium

1 4k Projector 4k Projector of resolution 3840x2160 Native resolution 1

2 Projector Mount or Projector Lift Projector mount or LCV projector lift to do control with room control AV system 1

3 Projection Screen Seamless projection Screen with 8 feet (2.4 m) high by 14 feet (4.3 m) wide. 1

4 Document camera, Laptop, Blu ray Player, Satellite TV, Source equipment's for content play 1
4k Camera, desktop PC (Source & Monitoring)

5 HDCP-Compliant Video wall Processors with eight in- Video wall processing for video walls with up to six displays,HDCP-compliant HDMI inputs and outputs support resolutions up to 1920x1200 and 1080p/60 3
put four output High speed, dedicated video/graphic bus delivers real-time performance High quality image upscaling and downscaling Bezel compensation for flat-panel dis-

plays processor integrate easily into environments that incorporate a 4K display such as lobbies, auditoriums, and simulation systems

6 Surround speaker Frequency Response (+/-3 dB) 90 Hz - 16 kHz Frequency Range (-10 dB) 80 Hz - 16 kHz Nominal Coverage Pattern (H x V) 90° x 60° (rotatable high-frequency 7
horn) Power Handling, long-term continuous Bose extended-lifecycle test⁴: 200 W AES transducer test⁵: 250 W Power Handling, Peak Bose extended-
lifecycle test⁴: 800 W AES transducer test⁵: 1000 W Sensitivity (SPL / 1 W @ 1 m) Bose extended-lifecycle test⁴: 91 dB AES transducer test⁵: 91 dB Calculated
Maximum SPL @ 1 m Bose extended-lifecycle test⁴: 114 dB AES transducer test⁵: 115 dB Calculated Maximum SPL @ 1 m, peak Bose extended-lifecycle

7 Subwoofer Compact 1 x 12" (305 mm) configuration frequency Response (+/-3 dB) 40 Hz - 280 Hz Frequency Range (-10 dB) 36 Hz - 290 Hz Nominal Dispersion Omni-directional below 200 Hz Sensitivity (SPL / 1 2
designed to provide bass augmentation Allows minimal W @ 1 m) 91 dB SPL Maximum SPL @ 1 m 117 dB SPL (123 dB SPL peak) Long-Term Power Handling 400 W (1600 W peak) Nominal Impedance 8 Ω
-height arrays when used with LT mid/high loudspeak-
ers.
8 PowerMatch® PM8500 / PM8500N power am- Maximum Rated Power 4000 W (500 W x 8 channels at 4 ohms) Class d Amplifier 2

plifier

9 Series/2 Cable Access Enclosure for AV Con- Accommodates one Series/2 AC 100 Series or AC+USB 200 Series Power Module, plus three Retractors, eight AV cables, or three AAP - Architectural Adapter 2
nectivity and AC Power Plates Slim enclosure is ideal for conference tables, desks or study carrels, lecterns, and other work spaces where space is at a premium Patented modular
design for fast assembly and serviceability Retractor bracket, Cable Pass-Through bracket, and AAP bracket included; Retractor modules, cables, and AAP

plates sold separately Retractor Bracket holds three Retractor Series/2 or Retractor Series/2 XL cable retraction modules Connectivity Bracket supports up to
three single-space AAPs

10 Control Processor with IPAD Control Supports TouchLink® Pro touchpanels and eBUS® button panels,Supports secure industry standard communications protocols Supports LinkLicense® Two bi- 1
directional RS-232 serial ports with software handshaking One bidirectional RS-232/RS-422/RS-485 serial port with hardware and software handshaking Two
IR/Serial ports for one-way control of external devices
11 CENTRAVERSE™ CVG12D 12” (30.5 CM) Cardioid polar pattern with tailored response for speech, Integrated desktop base,Optional Mute Function with LED lighting,12” (30.5 cm) gooseneck Inline 6
GOOSENECK MICROPHONE WITH INTEGRAT- preamp Dual-section gooseneck enables ease of positioning and placement options XLR cable/connection. Plug-and-play solution for minimized setup times

ED DESKTOP BASE AND INLINE PREAMP,
