Training Room Solution with Annotation and Presentation.

Divisible Classroom AV SOLUTION

OVERVIEW

A corporate classroom will be used for training, seminars,
and presentations, The system needs to be capable of dis-
playing both digital and analog source, types in a high quali-
ty, professional manner. There will be a divider wall to split

the room into two classrooms for separate meetings. Re-
sources in each room will be exclusive to each other when
the rooms are separated,and shared when the rooms are

combined. It is also very important that the system be relia-
ble and simple to operate, regardless of which mode the
room is configured.
An important first step in AV system design is a

meeting with the customer to assess the essen- Why US ?
tial AV application needs.
Display System We are the authorized partner of world known AV organization like Extron, Clearone, BOSE, Lifesize, Sharp,

A ceiling-mounted projector and a ceiling- Samsung & Crestron, we have decade of experience in AV technology and successful implementation, we
NEEDS ASSESSMENT mounted motorized screen are to be installed have our in-house team for designing to implementation to after sales onsite services, we know the tech-
in each partitioned room. The screens shall be nology and their challenges, and always advise our customers for a best buy, we provide all the products
 Staffing : The system will be operated by corporate training staff, Hu-
84 inches wide (210 cm), and the bottoms of and solutions you need for designing AV systems to suit any applications, from basic switching system with
man Resources, and managers.
the image areas are to be 40 inches (100 cm) a single display, all the way upto large scale AV distribution installations for an entire university or corpo-
 Sources : There will be a lectern for each divided room space, The
AFF. The aspect ratio of the screens will match rate campus, we can even provide the means for you to integrate AV between locations around the world.
lectern will have one HDMI, one DisplayPort, and one analog VGA
that of the projectors. The native resolution of
input available to the presenter. Switching System Audio System Control System
the projectors is to be 3840x2160, resulting in a
A matrix switcher will provide
 Inputs will be capable of supporting signals up to 4K.Cables will be 16:9 aspect ratio. The switcher will facilitate audio An 7 inch Touch Link touch panel will be sur-
extended through the lectern work surface. In a central equipment management of video and audio source selection with audio embed- face-mounted into each of the two lecterns,
source selection and distribution.
area, there will be two cable TV receivers and two Blu-ray players. Sources & Connectivity ding and de-embedding as needed. and serve as a primary control interface for
The DTP inputs will receive signals The integrated 100 watt, 70 volt
 Display Requirements Each divided room will have a ceiling-mounted the system. The two panels easily integrate
Two lectern-mounted laptop source input from the two lectern transmitters, amplifier will power six Bose distrib-
projector. A motorized retractable screen will be located along each into the built-in Gigabit Ethernet switch of
locations will be provided. Each location while the two DTP outputs will be uted ceiling loudspeakers for one of
room’s front wall. The projectors will operate independently of each used to extend signals to the two the partitioned rooms. An external the matrix switcher. Specifying License will
other in order to display separate content per room, or the same will provide one HDMI, one DisplayPort, projectors via shielded CATx cables Amplifier mono amplification to six
content if the rooms are combined. and one VGA cable. The cables are to be Bose loudspeakers in the other allow a specially customized GUI for each of
connected to Extron DTP T DSW 4K 333 and receivers. Each receiver is to the touch panels, as well as master control
 Audio Requirements The two divided room spaces will have separate be securely mounted above the room. The audio input signal will
switching transmitters in the lecterns. GUIs on staff iPads. The control system will
distributed audio systems that can function independently or togeth- projector in a workmanlike man- come from one of the analog audio
er depending on room configuration. Each video source will provide Each transmitter will extend signals over a ner. By using independent outputs outputs of the DTP Cross Point. Its be provided by the DTP CrossPoint, and will
stereo audio. Additionally, each lectern will have a wired gooseneck shielded CATx cable to the matrix switch- integrated digital signal processor is provide control of source selection, audio
on the DTP Cross Point, each room
microphone for voice lift within the respective rooms. er in the central equipment rack. Two Blu- to be used for audio source switch- volume levels, the motorized screens, the Blu
can display an independent source. ing, mixing, and routing to the out-
 Control Requirements The user interface should be a simple-to-use ray players and two cable TV receivers will When the two rooms are com- puts, as well as processing for the -ray players, and selecting TV channels.
GUI.Each lectern should have a control surface that provides the abil- also be housed in the rack. bined, the matrix can provide the program source inputs and lectern .
ity to power the system on and off, select an input source, adjust vol- same output to both projectors, or microphones.
ume level,and control a Blu-ray player and cable TV receiver.The end
separate content to each projector
user has requested the ability to provide secondary points of control at the user's discretion.
from mobile devices.
