Bill Of Quantity Details

No. Product Description QTY

1 LED DISPLAY true 4k 60 inches LED Display True 4k o of resolution 4096 X 2160 p 2

2 Wall Mount Kit For display Super Large Articulating TV Wall Mount. 2

Arms can be extend to 910mm.Max Load Capacity 200lbs(90kg),Extension From 3.8”(97mm) to 36”(910mm),Tilt +15°/-5° ,Swivel 180° Horizontal
Adjustment ±5°

3 Three Input Multi-Format Switcher with Inte- Transmits DisplayPort, HDMI, or VGA plus control and analog audio up to 330 feet (100 meters) over a shielded CATx cable 2
grated Long Distance DTP Transmitter and Au- Auto-switching between inputs Supports computer and video resolutions up to 4K,Analog stereo audio embedding
dio Embedding

4 Receiver for HDMI Receives HDMI plus control and analog audio up to 230 feet (70 meters) over a shielded CATx cable, Supports computer and video resolutions up 2
to 4K

5 7” Wall Mount Touch Link Pro Touch panel 7" LCD touchscreen with 800x480 resolution and 18-bit color depth, Faster processing and more memory, Compatible with all IP Link Pro control 1
processors, Power over Ethernet allows the touch panel to receive power and communication over a single Ethernet cable, eliminating the need

for a local power supply - Poe injector sold separately, Built-in speaker with improved audio performance Light sensor adjusts screen brightness
as the ambient room lighting changes
6 8x4 Seamless 4K Scaling Presentation Matrix All in one 8x4 4K matrix switcher, scaler, audio DSP with AEC, audio power amplifier, and control processor Two DTP inputs and six HDMI inputs 1

Switcher Two HDMI outputs and two independently scaled DTP outputs 4K matrix switching and scaling with selectable seamless transitions and logo key-
ing
7 Control Processor with IPAD Control Supports TouchLink® Pro touchpanels and eBUS® button panels,Supports secure industry standard communications protocols Supports LinkLi- 1
cense® Two bidirectional RS-232 serial ports with software handshaking One bidirectional RS-232/RS-422/RS-485 serial port with hardware and

software handshaking Two IR/Serial ports for one-way control of external devices

8 12x8 ProDSP Proc. w/AEC and POTS Eight channels of AEC - acoustic echo cancellation, Eight inputs with FlexInput capability to select between analog or Dante inputs on 1
DMP 128 AT models Dante audio networking provides a wide range of expansion capabilities

9 Power Amplifier Reliable 2 x 120 W Class-D amplification optimized for 70/100V high-impedance applications 1

10 Ceiling Speaker Full-range loudspeaker with a single 2.25" (57 mm) driver in a ported enclosure to deliver a 140° conical coverage pattern and clear, intelligible 8
music and speech reproduction for flush-ceiling or pendant mount applications

11 Ceiling Speaker Premier high-performance, extended-range, flush-mount loudspeaker designed for foreground music and speech reproduction in a wide range 4
of installed applications. High output and wide, 160° conical pattern with a frequency range down to 60 Hz.

12 CENTRAVERSE™ CVG12D 12” (30.5 CM) Cardioid polar pattern with tailored response for speech, Integrated desktop base,Optional Mute Function with LED lighting,12” (30.5 cm) goose- 2

GOOSENECK MICROPHONE WITH INTEGRAT- neck Inline preamp Dual-section gooseneck enables ease of positioning and placement options XLR cable/connection. Plug-and-play solution for
ED DESKTOP BASE AND INLINE PREAMP, minimized setup times

** Kindly Note the above line items are not a complete BOQ the final BOQ will be designed once the details will receive to us , ** The input source device and output source device is on customer requirement and will decide
after mutual discussion. The quantities mentioned in boq will varies as per the customer application.

SSB INFOSYSTEMS PRIVATE LIMITED– Confidential
