Bill Of Quantity Details

No. Product Description QTY

Ante Room

1 4k Led Display True 4k Led Display For Looby 2

2 Wall Mount Wall Mount For LED display 2

3 XTP 4K Fiber Optic Scaling Receiver for HDMI Receives video with embedded audio, bidirectional RS 232 and IR control, and Ethernet over one fiber optic cable, Advanced Extron Vector™ 4K scaling tech- 3
nology, Selectable output rates from 640x480 to 3840x2160, HDCP compliant, Bidirectional RS‑232 and IR insertion for AV device control, Ethernet extension

4 5” Wall Mount TouchLink Pro Touchpanel 5" capacitive touchscreen with 800x480 resolution and 16 million colors, Faster processing and more memory, Compatible with all IP Link Pro control proces- 1
sors, Power over Ethernet allows the touchpanel to receive power and communication over a single Ethernet cable, eliminating the need for a local power
supply - PoE injector sold separately, Built-in speaker with improved audio performance, Digital input allows for a connection with a variety of devices, such
as sensors, switches, and relays

Centralised Equipment

1 IP Link Pro Control Processor Supports TouchLink® Pro touchpanels and eBUS® button panels, Supports secure industry standard communications protocols, Supports LinkLicense®, Six bi- 2

directional RS-232 serial ports with software handshaking, Two bidirectional RS-232/RS-422/RS-485 serial ports with hardware and software handshaking,

2 Wall Mount Wall Mount For LED display 2

3 Media Player Media Player blue ray 4k 2

4 Modular Digital Matrix Switchers from 50 Gbps digital backplane supports an 8K future, Wide selection of local, twisted pair, and fiber optic input and output matrix boards,RS‑232 insertion from 1

4x4 to 32x32 with Speed Switch Tech- the Ethernet control port, Remote power to select XTP twisted pair transmitters and receivers, Audio breakaway, Modular, field-upgradeable and hot-
swappable design

** Kindly Note the above line items are not a complete BOQ the final BOQ will be designed once the details will receive to us , ** The input source device and output source device is on customer requirement and will decide after mu-
tual discussion. The quantities mentioned in boq will varies as per the customer application.
