Bill Of Quantity Details

No. Product Description QTY

Meeting Room– Cont

15 Audio Processor 12 Mic/Line inputs with AEC,Built-in VoIP – 2 lines +3 lines (license), Built-in Telco with ClearEffect™processing,Built-in USB for PC-based conferencing, Built- 1
in Dante for networked audio, Reduced footprint and power consumption

16 12" Table top Touch Link Pro Touch panel 12” capacitive touchscreen with 1280x800 resolution and 16 million colors Faster processing and more memory Full-motion video preview and monitoring 1
with HDMI and XTP inputs Compatible with all IP Link® Pro control processors PoE+ delivers power and communication over a single Ethernet cable, elimi-
nating the need for a local power supply - Power injector sold separately Built-in speakers provide stereo audio

EXECUTIVE CONFERENCE ROOM

1 4k Led Display True 4k Led Display For Video conferencing 2

2 Projector Mount or Projector Lift Projector mount or LCV projector lift to do control with room control AV system 2

3 Projector 5500 Lumens WUXGA Projector with 123 inches diagonal projection Screen 1

4 XTP 4K Transmitter for HDMI Transmits video, audio, bidirectional RS 232 and IR, and Ethernet up to 330 feet (100 meters) over a shielded CATx cable, Supports computer and video reso- 3

lutions up to 4K, HDMI loop-through with selectable audio control, HDCP 2.2 compliant, Remote power capability, Extron XTP DTP 24 shielded twisted pair
cable is strongly recommended for optimal performance

5 Universal XTP Transmitter for VGA Transmits analog video, audio, bidirectional RS-232 and IR, and Ethernet up to 330 feet (100 m) over a shielded CATx cable, Supports computer and video res- 1

olutions up to 1920x1200, including 1080p/60,Supports RGBHV, HD component video, S-video, and composite video signals, Remote power capability, Bidi-
rectional RS-232 and IR insertion for AV device control ,Extron XTP DTP 24 shielded twisted pair cable is strongly recommended for optimal performance sys-

6 Three Input Switcher with HDMI Output and Transmits DisplayPort, HDMI, or VGA video, audio, bidirectional RS232 and IR, along with Ethernet up to 330 feet (100 meters) over a shielded CATx cable, 3

Integrated XTP 4K Transmitter Supports computer and video resolutions up to 4K, HDMI output enables local display of the selected input, HDCP 2.2 compliant, Extron XTP DTP 24 shielded
twisted pair cable is strongly recommended for optimal performance, One DisplayPort, one HDMI, and one VGA input

7 VC Unit With Dual Camera Brings SIP/H.323 videoconferencing, Skype for Business and Spontania cloud video and web conferencing into a single appliance, Perfect for both single-site 1

and multi-site interactive collaboration, Multi-purpose solution makes it perfect for multiple applications and environments, Multi-source collaboration with
simultaneous capture of up to 4 video input sources, Single point of support and maintenance for your collaboration and conferencing needs
8 Series/2 Cable Access Enclosure for AV Con- Accommodates one Series/2 AC 100 Series or AC+USB 200 Series Power Module, plus three Retractors, eight AV cables, or three AAP - Architectural Adapter 3
nectivity and AC Power Plates Slim enclosure is ideal for conference tables, desks or study carrels, lecterns, and other work spaces where space is at a premium Patented modular

design for fast assembly and serviceability Retractor bracket, Cable Pass-Through bracket, and AAP bracket included; Retractor modules, cables, and AAP
plates sold separately Retractor Bracket holds three Retractor Series/2 or Retractor Series/2 XL cable retraction modules Connectivity Bracket supports up to
three single-space AAPs

9 Control Processor with IPAD Control Supports TouchLink® Pro touchpanels and eBUS® button panels,Supports secure industry standard communications protocols Supports LinkLicense® Two bi- 1
directional RS-232 serial ports with software handshaking One bidirectional RS-232/RS-422/RS-485 serial port with hardware and software handshaking Two
IR/Serial ports for one-way control of external devices
10 Power Amplifier Reliable 2 x 120 W Class-D amplification optimized for 70/100V high-impedance applications 1
