LOCKS

Horizontal Locking

Rod Support Bracket Internal Locks — with Handle

ELECTRICAL
„ Material: Glass fibre polyamide. „ Drawing shows Part No. 65868 right hand version, Part No.
65878 is left hand version
„ Material: Glass fibre polyamide/acetalic resin tongue.
„ All metal parts zinc plated steel.

EMERGENCY

B
C
A D

GENERAL
E

HANDLES
Part No. A B C D E F G Kg Finish
Part No. A B C D E Kg Finish 65868 85 51 12 10 47 17 42 0.245 BPM

65568 65 13 8 43 23 0.015 BPM 65878 85 51 12 10 47 17 42 0.245 BPM

Connector Kit
HINGES

„ The Handle can be positioned at any point on the rod by
inserting the supplied Roll Pin after drilling. INTERIOR LIGHT
„ Material: Zinc plated steel pin
„ Use with handle Part No. 60768 external locking hand WITH BLUE
NIGHTLIGHT
IRONWORK

CAN BE RECESSED OR SURFACE
FIT USING PROVIDED BASEPLATE
LIGHTING

Plastic housing to reduce weight
Frosted lens to hide LED modules
Blue fibre optic travel / night light
LOCKS
Enclosed rear casing
Clip-On faceplate to conceal fixing points
Approval :- UK CA & EMC
12/24V. Lux at 1 m 150
Colour Temp 6600k Ra 83.5 approx
STEPS
Depth 15mm Plant-on or 6mm semi recessed
Part No. A B C D Kg Finish
62288 55 5 60 50 0.02 ZPS
62298 65 5 60 50 0.025 ZPS
67628 75 5 60 50 0.025 ZPS See page 125

VENTILATION
