Page 8 - STANDARD EARTH BAR CATALOGUE
P. 8
TWIN ISOLATION LINK EARTH BARS
• Manufactured from 60 x 6mm HDHC C101 Radius Edge Copper Bar
• Rated at 1000amp AC / DC
• 40mm Stud Centres with M10 x 40mm Brass Studs as Standard
• Mounted on a “Top Hat” Aluminium Sec-on with M8 x 30mm Halogen Free
Hexagonal Stand Off Insulators
• 4 - 54 Ways as Standard
• Aluminium Sec-on pre-drilled with 5mm holes for fixing
• Maximum Cable size is 185mm
• 48 Hour turn around on Custom sizes!
Price
Part Number Descrip-on Length Weight Lead Time
(ex VAT & Delivery)
EB4L2 DUAL LINK 4 WAY EARTH BAR 580mm 2.5 kg 2 Days £109.50
EB6L2 DUAL LINK 6 WAY EARTH BAR 660mm 2.8kg 2 Days £115.50
EB8L2 DUAL LINK 8 WAY EARTH BAR 750mm 3.3 kg 2 Days £121.50
EB10L2 DUAL LINK 10 WAY EARTH BAR 820mm 4 kg 2 Days £127.00
EB12L2 DUAL LINK 12 WAY EARTH BAR 900mm 4.3 kg 2 Days £132.50
EB16L2 DUAL LINK 16 WAY EARTH BAR 1060mm 5.8 kg 2 Days £144.50
EB18L2 DUAL LINK 18 WAY EARTH BAR 1140mm 6.0 kg 2 Days £151.00
EB20L2 DUAL LINK 20 WAY EARTH BAR 1300mm 6.2 kg 2 Days £165.00
EB24L2 DUAL LINK 24 WAY EARTH BAR 1460mm 7.7 kg 2 Days £176.50
EB30L2 DUAL LINK 30 WAY EARTH BAR 1700mm 9.3 kg 2 Days £194.50
EB36L2 DUAL LINK 36 WAY EARTH BAR 1940mm 11 kg 2 Days £212.00
EB40L2 DUAL LINK 40 WAY EARTH BAR 2140mm 12.5 kg 2 Days £285.00
EB48L2 DUAL LINK 48 WAY EARTH BAR 2460mm 13.5 kg 2 Days £280.00
EB54L2 DUAL LINK 54 WAY EARTH BAR 2700mm 14.5 kg 2 Days £300.00
7
