Rod placement check
To verify that the rod is fully seated in the screw heads, insert the MS1-A311
into the screw extender and check that the laser mark is visible.
The laser mark is not The laser mark is visible The laser mark is visible
visible. There is no rod and not flush with the and flush with the
in the screw head. screw extender. Rod screw extender. There
reduction is necessary. is no need to reduce
the rod.
GMS2-ST_04GB See package insert for labeling limitation 42
