Compression-Distraction

Select the desired action (compression,

Trigger distraction) with the trigger, and turn the

turnkey.

Distraction Compression

Once the correction has been performed, it is possible to perform the final tightening

on the setscrew which was not used as the reference screw, while maintaining the

compressor-distractor in position.

Remove the distractor-compressor by pulling it from the screw-extenders and

removing the two counter-torques.
