Compression-Distraction















 Select the desired action (compression,


 Trigger   distraction) with the trigger, and turn the



 turnkey.



     Distraction                                  Compression























 Once the correction has been performed, it is possible to perform the final tightening


 on the setscrew which was not used as the reference screw, while maintaining the


 compressor-distractor in position.






 Remove  the  distractor-compressor  by  pulling  it  from  the  screw-extenders  and



 removing the two counter-torques.














 GMS2-ST_04GB   See package insert for labeling limitation                                                 57
