Screw Extender Removal

Release the screw extender (MS1-A211/MS1-A214) by

screwing the nut (1) counter clockwise and sliding the

ring (2) up to unlock the assembly.

The Extender Wrench (MS1-A213) can be

used to help unlock and remove the screw

extender by unscrewing the nut (1)[A] or by

A B lifting up below the ring (2)[B].

Repeat the previous surgical steps for all screws

GMS2-ST_04GB See package insert for labeling limitation 58
