Page 65 - February 2018-Turolight
P. 65

New XL LED Slim Flood Fixture



                                                                                                     Bracket Type










          SFV - Slip Fitter by vertical  SSF - Square Slip Fitter       HK - Hook                  WM - Wall Mounting


                                                               Hook installation
        ~5.51(140)  ~3.82(97)        ~5.51(140)  ~3.82(97)  ~1.97(50)                                ~12.80(325)

            ~9.65(245)                   ~9.65(245)                ~8.9(226)  ~5.39(137)
            15°                        15°                                                    ~6.3(160)
                                                               Pole Installation  G0.75(19)


        ~12.80(325)                  ~12.80(325)                  ~6.3(160)  ~3.82(97)         ~5.51(140)  ~3.82(97)

                                                                          ~12.80(325)
                                        ~6.3(160)
                                                                    ~6.3(160)
           ~6.3(160)                       ~15.94(405)

       How our Model No. Works:
       Ordering Information

         NXL        SFL        60W       5         40        UNV         GL       C           WM            D
         Family   Fixture Style  Wattage  IES Classication  CCT (K)  Voltage  Lens Material  Lens Type  Bracket Type  Dimming
               SFL - Slim Flood  60W  5 - Type V  40 - 4000K  UNV - 120-277V  GL - Glass  C - Clear  WM - Wall Mounting  D - 0~10V Dimming
                               80W              50 - 5000K  HVU - 347-480V             SFV - Slip Fitter by vertical
                              100W                                                     SSF - Square Slip Fitter
                                                                                       HK - Hook
                                                                                       SFL - Slip Fitter in Line
                                                                                              (Road Lighting)
